Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
Specifications
Brand Name :
RILANT
Model Number :
SZHG-2500N
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
2 sets per month
Delivery Time :
45 working days
Packaging Details :
Standard export package
Product Name :
Steel coil slitting machine steel sheet slitting line metal slitting cutting machine
Material :
Carbon Steel,Stainless Steel
Keyword :
Steel strip cutting machine
Max. Coil Width :
800-2500 mm
Voltage :
380V,50Hz,3 Phase
Rated Power :
120 KW
Dimension(L*W*H) :
10000*2000*2500 mm
Applicable Industry :
Machinery,energy,: Construction works etc
Weight :
20 ton
Description

Stainless Steel Coil Slitting Machine Cut To Length Line Metal Plate Decoiling Cutting Machine

Cutting to length lines are technological solutions to ensure the best quality of products in terms of flatness and dimensional tolerances. Our equipment is designed to reduce the idle time and achieve a highest production.

Smiko manufacture cut to length lines for Steel, Stainless steel, Copper & all types of non ferrous metals. The strip material is transferred from the coil, leveled & cut-to-length.

Our Cut to Length lines are designed according to customized requirement of the customer.We design a line concept that offers the most economical solution while achieving an increase in production and a higher product quality.

Features:
* High output/throughput and flow rates by rigorous minimization of tooling times and high productions speeds

* Extremely good flatness of sheets by using “four-high” and “six-high” levellers.
* Cutting accuracy and angularity of sheets.
* Cutting with little burr.
* High stacking accuracy by using individual stacking systems

Main Technical Parameter
NameModel 0.11-0.8×1500 0.20-2.0×1600 0.3-3.0×1800 0.5-4.0×1800
Coil Thickness(mm) 0.11-0.8 0.3-2 0.3-3 0.5-4.0
Coil Width(mm) 600-1500 800-1600 800-1800 800-1800
Cutting Length Range(mm) 10.0-99999 10.0-99999 10.0-99999 10.0-99999
Stacking Length Range(mm) 300-4000 300-4000 300-4000 300-4000
Cutting Length Precision(mm) ±0.3 ±0.3 ±0.5 ±0.5
Leveling Speed 35pcs 35pcs 35pcs 35pcs
(2000mm/min)
Coil Weight(T) 10 10 20 20
Roll Dia.(mm) 75 85 85 100


1. Specifications:Technical Parameters of roll slitting machine:

a. applied to : HR,CR

b. Tensile strength:b≤500Mpa,S≤300Mpa

c. thickness:0.5-2.0mm

d. width:500-1500(Max)

e. coil ID: 508mm

f. coil OD:1600mm(Max)

g. weight :15T(Max)

h. diameter of leveling rollers: 65mm

i. distance of leveling rollers:70mm,

j. material of leveling roller:GCr15,hardness:HRC55-60

k. total weight of machines:around 30T

2. Finished products parameters:

a. diagonal tolerance:≤±1mm/2000mm

b. length tolerance:≤±0.5mm/2000mm

3. Other parameters :

a. power :380V/50Hz/3Ph

b. line speed:0-60m/min

c. capacity :around 100Kw

d. area of the whole production line(about) 25m(L)X7m(W)

e. people of operation: 1 technician and 2 general workers

f. color of the machines: grass green

Composed devices of roll slitting machine:

1.Hydrauliccoil car

2.Hydraulic decoiler

3.Slitting machine

4.Scrap winder

5.Tension stand

6.Hydraulic recoil

7.Unloaded car

8.Hydraulic control system

9.ELectric control system

Steel coil parameters Material HR,CRS and GI
Tensile strength δb≤450Mpa,δS≤260Mpa
Steel thickness 0.3-3mm
Steel width 500-1600
Steel coil I.D φ480-520 mm
Steel coil O.D φ1600mm(Max)
Steel coil weight 15T
Slitter parameters knife pivot diameter Ф200 mm
Knife pivot material 40Cr
Blades specification Φ200mmXφ340mmX15mm
Blade material 6CrW2Si
Slit parameter Max slit quantity 5 pcs (3mm) 25 pcs(0.3mm)
Width precision ≤±0.05mm/2M
Mini slit strips width 20mm
Other parameters Power 380V/50Hz/3Ph
Line speed 0-100m/min
Capacity 210 Kw
Whole line Dimension 25m(L)X8m(W)
Operator needed 1 mechanical engineer ,2 common workers
Line direction From right to left(Face to machine)
Machine color White grey

Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel

Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel

Automatic HR Slitting Machine 15T Ss Sheet Cutting Machine Carbon Steel
