ET20 All Metal Sheet Neon Signs Making CNC Channel Letter Bending Machine for Choice

Specifications

Place of Origin :

Tianjin, China

Brand Name :

Ejon

Condition :

New

Video outgoing-inspection :

Provided

Machinery Test Report :

Provided

Marketing Type :

New Product 2024

Warranty of core components :

1 Year

Core Components :

PLC, Motor

Material / Metal Processed :

Aluminium alloy, Aluminum, ALLOY, Brass / Copper, Stainless steel, Carbon steel, Aluminum profile

Automation :

Automatic

Warranty :

1 Year

Weight (KG) :

800

Key Selling Points :

Multifunctional

Applicable Industries :

Retail, Printing Shops, Manufacturing Plant, Advertising Company

Showroom Location :

Egypt, Turkey, United States, Viet Nam, Brazil, Russia, Spain, Thailand, South Korea

Product name :

channel letter bending machine

Function :

Auto Feeding+bending+slotting+notching

CNC or not :

CNC Letter Auto Bending Machine

Operation principle :

High Precision Automatic Feeding

Control System :

7 axis control system (3 servo axis control)

Applicable material :

Stainless steel, galvanized plate, Aluminum plate, aluminum profile

Bending system :

Double Blade Alternate Bending System

Bending thickness :

0.4~1.2mm

Slotting System :

Plane cutter/milling wheel cutter

Extra Services :

Technical Support online, video

MOQ :

5 sets

Price :

$12,000.00/sets >=5 sets

Description

Product Description

EJON ET20 Versatile Sign Board Led Lettering machine

Dobladora de Letras Multifuncional

FEEDING SYSTEM

1. The material clamps are casted which can avoid scratching the material, meanwhile improving the feeding holding. Using air pressure to press the material, avoid material uneven and ensure the smooth feeding.

2. The double ball screw is matched with nylon gear transmission for precise positioning, which greatly improves the feeding speed and stability of the machine.

SLOTTING SYSTEM

1. Adopts double cutter independent slotting structure, easily deal with various materials, imported linear guide rail with ball screw, combined with high-power servo motor, to ensure the stability and consistency of slotting.

2. The slotting tool adopts imported high-strength alloy plane cutter , each cutter has 8 edge angles, no need to sharpen the cutter only change different angles , prolong the service life and greatly improve the processing efficiency.

PLANE CUTTER SLOTTING

MILLING WHEEL CUTTER SLOTTING

BENDING SYSTEM

Double bending tools alternating bending structure:

1. Casted by ductile iron, with good vibration absorption, high structural strength, which reduces the number of parts splice.

2. Configuration of high-power servo motor, ensures the high-speed bending work, bending mechanism does not deform easily, effectively improves the positioning accuracy and high-speed bending stability.

Specification

ITEM	VALUE
Working Space	2400mm1100mm1500mm
Weight (KG)	700
Power	AC220V、50Hz、2.0kW
File Format	Dxf.Plt.Ai
Function	Auto Feeding+bending+slotting+notching
Feeding System	Mechanical hands circulating clamping feeding
Accuracy	±0.1mm
Control System	7 axis control system (3 servo axis control)
Bending System	Double Blades Alternate Bending System
Suitable Material	Stainless steel, galvanized plate, Aluminum plate
Bending Thickness	0.4~1.2 mm
Min. Bending Angle	R6
Slotting System	Plane cutter/milling wheel cutter
Slotting Trip	20~200mm

Finished Letters

Company Profile

Packing & Delivery

Item	Value
Package Size	1410mm780mm1600mm
Packing material	fumigated wooden case, PE film or according to customer's special request
Weight	750kg
Port	Tianjin port
Lead Time	1 Set: 7 days 2 Sets: 15 days >2: To be negotiated
Freight way	shipping, Land transportation

Exhibition

FAQ

1. Why Choose Us?

* Profesional Manufacturing

1. National patent technique of independent intelligent property right
2. More than 10 years of manufacturing experience in this industry
3. About 10,000 m² factory to guarantee the production, storage and supplying
* Easy to Operate
You’ll spend only a few minutes learning how to use the machine through the simple operation interface and our video
* Quality Services
1. You can get highly customized product according to your demand because of our self-developed software, which can greatly shorten the reconfiguration time and improve the work efficiency.
2. Pre-sale service: Inquiry and consulting support; Sample testing support; View our Factory.
3. After-sale service: Installand and use Training online or by telephone always at your service, no need to worry about any problem of the machine

2. How can we guarantee the quality?

IQC (Incoming Inspection) → IPQC (InPut Process Quality Control) → OQC (Outgoing Quality Control) → QA ( Finished product Quality Assurance) layer upon layer to ensure the quality and commitment to customer service 3. Do you have any other related machine or spare parts to sell? You can tell us your demand and we'll recommend a suitable one to you.
laser welder (click me!)

automatic slotting machine (click me!)

deburring machine (click me!)
channel letter grinding machine (click me!)

laser cutting machine (click me!)
and related spare parts and materials.
You can buy all of these at a lower price especially when you have made a big order or need a long-term supply.

4. What services can we provide? Accepted Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES； Accepted Payment Currency: USD, CNY; Accepted Payment Type: T/T,L/C, Credit Card, Western Union, Cash; Language Spoken: English, Chinese, Spanish, French, Korean

5. How about the after-sale service?

We will respond to your demand within 24 hours via email or the platform's official communication tool, and send relevant
documents or materials remotely, providing technical support online.
In the case of non-man-made damage to the machine, within the scope of free parts agreed by our both part, we will send free parts within 48 hours (except imported parts or customized parts).

6. How to choose the channel letter bending machine?

CLICK PHOTO TO GET MORE DETAILS !

Notching, Flanging, V-Cutting, Bending

Diverse metal materials applicable: stainless steel, aluminum plate, galvanized plate, etc.

Muiti-function: feeding, slotting, flanging, V-cutting, bending, cutting

OUR STAR PRODUCT

Aluminum only

Limited to process aluminum plate.

Single-function and Low price

Multiple materials Processing

Applicable for:

stainless steel, aluminum plate, galvanized plate, aluminum profile etc.

High Performance-to-Price Ratio

Generally First Choice

Metal sheet deburring machine

To remove burrs and polish the surface of machined parts, stamping parts, laser cutting metal sheet, etc.

Letter edge grinding machine

To make the letter edge more smooth and round and get a wonderful appearance.

Laser welding machine

Weld diverse metal with high speed, efficiency and small welding deformation.

Channel letter welding machine

To weld the letter border together with the surface.

Laser cutting machine

To cut the metal sheet into desired shape.
