Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Specifications
Place of Origin :
China
MOQ :
5 sets
Price :
$5,500.00/sets >=5 sets
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Hot Product 2024
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Gear
Material / Metal Processed :
Aluminum, Stainless steel, Carbon steel
Warranty :
1 Year
Weight (KG) :
350
Key Selling Points :
Multifunctional
Applicable Industries :
Other, Advertising Company
Showroom Location :
Egypt, United States, Viet Nam, Philippines, Saudi Arabia, Russia, Thailand, UAE, Australia
Product name :
Channel Letter Bender Machine
Material width :
10-120mm
Material thickness :
0.4-1.2mm
Processing Material :
stainless steel,galvanized plate,flat aluminum
Min.Bending Angle :
R6
Control system :
4 Axis Control System
Slotting method :
Plane cutter
Bending method :
Double-bends alternate bending
Fedding method :
Rolling continuous feeding
Power :
AC220V,50Hz,2.0Kw
Description
Product Description
EJON Y6 High Efficiency Aluminum Sheet and Stainless Steel Channel Letter Bending Machine for 3D sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
SPECIFICATIONS
Feeding system
Rolling continuous feeding system
Slotting System
Plane cutter
Bending System
Double blade alternate bending system
Suitable Material
Stainless steel, Galvanized steel, Aluminum plate
Material Height
Stainless steel,Galvanized steel,Aluminum plate:20~120mm
Material Thickness
0.4~1.2mm
Accuracy
±0.1mm
Min. Bending Angle
R6
File Format
Dxf.Plt.Ai
Power
AC220V,50Hz,2.0Kw
Control System
4 axis control system (2 axis servo control)
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign

Main Features

1) The feeding support adopts an integral casting structure, which effectively avoids the deformation in the feeding process and ensures the stability of feeding.

2) The bending system adopts structural castings, integral casting, to ensure the stability of high-speed bending.

3) The slotting and bending adopt 750W high-power servo motor which accurate positioning, fast response, stable operation, and effectively improve the system's rapidity and stability.

Detailed Images
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign

Machine Parts

The casting on Clamping increases the grasping force, meanwhile does not scratch the material

Main Features

The encoder module is the key component of the the relation equipment precision , and the precision casting is used to ensure the performance of the high precision encoder.

Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Supporting Facility
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign

Computer

To use the device, you need to install the control card in your computer and then connect to the bending machine and install the software.Computer configuration : XP system or window7 32-bit system, and requires a PCI card slot to install the control card.

Pump

The use of equipment should be equipped with air compressor, we suggest that the selection of more than 4kw, the gas flow is 0.6m³/Min.

File Format

The software of bending machine is self-developed. Import file format supports .Dxf.Plt .AI We recommend using Coredraw or adobe illustrator to complete the file after the export file to.Dxf.Plt.Ai format. Then open the operating software, select the document.

Our Service
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
* Size:1200*720*1480mm
* Weight:400KG
* Packaging details:The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tighter,we will use pe film for packing or pack it according to customers special request.
About us
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign

Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Y6 Aluminum Sheet And Stainless Steel Channel Letter Bending Machine For 3D Sign
Contact us
Company address: Tianjin Ejon Flying Science and Technology Co., LTD.12 Jingshun Road, Yixingbu Science Park, Beichen District, Tianjin, China
Ivy Liu
Tel:0086-17526997508
E-mail:ivy-ejon@tj-ejon.com
Whatsapp/Wechat:+0086-17526997508
