Place of Origin :Tianjin,china Brand Name:EJON

Conditon :New Model Type: ET20C Suitable Material : Stainless steel,Galvanized plate,Aluminum plate Automaic :Automatic

After-Sales Service:Video/Oline support,Engineers Service Power :CNC

Slotting Method :Plane &milling cutter slotting system slotting Trip:20-200mm

Bending Method:Double Blade Alternating Bending System Warranty of core:1 Year

Certification: CE Machine weight:800kg

Supply Ability

Supply Ability:8800 Sets/Year

Packing &Delivery

Packaging Details:The Export Non-Fumigation Wooden Box

Port :Tianjin Port Or other China Port

Delivery Time : 10-20 Working Days

Product Description

EJ0N ET20C full-automatic notching and flanging bending machine adds the function of

automatic notching and cutting for flat metal material on the basis of existing bending machine.

The notching and cutting are controlled by servo system,which is high precision,fast speed, strong stability.The software operation is simple,the processing graphics need not modify

the node,greatly improve the work efficiency,is the prefered model of high edge characters.

Manipulator alternated feeding structure,the material clamps are casted which can avoid

scratching the material,meanwhiles improving the feeding holding.Using air pressure to

press the material,avoid material uneven and ensure the smooth feeding.The double ball

screw is matched with nylon gear transmission for precise positioning ,which greatly improves

the feeding speed and stability of the machine.

Adopting plane cutter can slot all kinds of materials.The linear guideway is matched with

the ball screw,with 750W high-power servo motor,greatly improve the feeding speed and

stability.High strength alloy cutters are used for slotting knives,each knife has 8 angles,no

need to sharpen,greatly improve the working efficiency.

Double blading alternating structure,the curved knife structure cast by ductile iron,good

shock absorpton,high structural strength,reduced number of parts splicing,high-power servo

motor,high-speed bending work under the bending mechanism,the bending mechanism is

permanently deformed,which effectively improves the positioning accuracy and the stability

of the high-speed bending.

ET20C Machine part details

Feeding Parts :The feeding structure adopts double ball screw

with nylon gear transmission,ensuring smooth feeding and accurate positioning,greatly improving the feeding speed and

stability of the machine.

Notching &Flanging Parts:The notching and flanging are controlled by servo system,which is high precision,fast speed,

strong stability.Equipped with debris storage box,non-pollution,

more environmentally friendly.

Slotting Parts: Adopt 750W high-power servo motor,High strength alloy cutters are used for slotting

knives,each knife has 8 angles,no need to sharpen,greatly improve the working efficient.

Bending Parts: Double blade alternating bending system,the bending adopts 750W servo motor,fast response,stable operation,and effectively improve the system’s rapidity and

stability.

Cutting Parts:After the production,the machine automatically

cut raw material,processing efficiency is higher and safer.

Sample Showing

How to learn machine operate

1. Operation Manual U disk

Provide U disk with machine which have detail specific english operational manual and videos.

2. Network Service

Through Wechat,Whatsapp,Skype,E-mail,Team viewer provide online service.

3. Factory Visiting

Welcome customer to visit our factory to learn how to operate the machine.

Supporting Facility

Computer Pump File Format

To use the device,you need to The use of equipment should The software of bending

install the control card in your be equipped with machine is self-developed. computer and then connect to AIR compressor,we suggest Import the format supports

the bending machine and install that the selection of more Dxf.Plt.Ai.We recommend

the software computer. than 4kw,the gas flow is using Coredraw or adobe

Configuration:XP system or 0.6m3/Min illustrator to complete

window7 32-bit system,and the file after the export file

requiresa pcl card slot to to Dxf.Plt.Ai format.Then

install the control card. open the operating software,

select the document
