L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A179
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
CHINA
MOQ :
Depend the size of finned tubes
Price :
1-10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
1000 tons/month
Delivery Time :
30-60 days
Packaging Details :
Ply-wooden Case With Iron Frame
Type :
L Type Spiral Wound Fin Tubes
Standard :
ASTM A179
Material :
Base Tubes A179 and Aluminum Fins
Working temperature :
230℃
Use :
Radiators / Condensers / Evaporators / Air cooler, etc
Packing :
Ply-wooden Case With Iron Frame
Description

L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins

L-Type wound fin tubes are a type of heat exchanger tube used in various industrial applications to enhance heat transfer efficiency. They are characterized by fins that are wound around the base tube in an "L" shape, which increases the surface area for heat exchange.General materials of base tubes of wound finned tube are carbon steel, copper, alloy, stainless steel ; general materials of fins of wound finned tube are copper, aluminum 1060/1070, aluminum alloy 6063/6061.

ASTM A179 covers minimum-wall-thickness, seamless cold-drawn low-carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus.

Chemical Composition (%) max

Grade C Mn P S
A179 0.06-0.18 0.27-0.63 0.035 0.035

Mechanical Properties

Grade Tensile Strength min Yield Strength min Elongation in 2" or 50mm min
A179 47ksi (325 MPa) 26ksi (180 MPa) 35%

L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins

Advantages

Allows for more efficient use of space in heat exchanger designs.

The fins increase the surface area, improving the heat transfer rate between the tube and the surrounding medium.
Enhances the efficiency of heat exchange processes, potentially reducing operational costs.The fins are typically made from materials that resist corrosion and wear, ensuring a long service life.

Application

Heat Exchangers: Shell-and-Tube Heat Exchangers, Air Coolers, Condensers.
Power Plants: Boilers, Economizers, Superheaters.
Chemical Processing: Reactors , Process Heaters.
HVAC Systems: Heating, Ventilation, Air Conditioning Systems.

L-Type Wound Fin Tubes Carbon Steel ASTM A179 Base Tube With Aluminum Fins
