50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing
Specifications
Brand Name :
NL
Model Number :
PDF
Certification :
FDA
Place of Origin :
Shanghai, China
MOQ :
50 Meter/Meters (Min. Order)
Price :
$11.00 - $59.00 / Meter
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
5000 Meter/Meters per Week
Delivery Time :
Quantity(Meters) 1 -50 Est. Time(days) 7
Packaging Details :
Standard packing. If you have any special requirement, please tell us in time.
Material :
Silicone
Color :
White
Size :
3/16"~1-1/4"
Length :
50m/roll
Temp. Range :
-60℃~200℃
Processing Service :
Moulding, Cutting
Description

Double polyester Fiber Braid Reinforced Silicone Hose

Construction: Type PDF is manufactured from High purity platinum cured Silicone with double polyester fiber reinforcement.

Temp. Range: -60°C and 200°C.

Colour: White (Coloured covers available)

Applications: For transporting liquids at high pressure. Suitable for CIP and SIP cleaning.

Certification: FDA, USP, BFR, USDA, ISO 10993

Length: Standard maximum length is 20 meters, for a longer length, please contact us.

** PRESSURE DECREASE BY 1% FOR EVERY 1°C ABOVE 100°C.

Part no. ID OD Bending radius Work pressure Bursting pressure Vacuum
in. mm mm mm bar bar bar
PDF005 3/16" 4.8 13 27 25 75 0.91
PDF006 1/4" 6.4 16 30 24 72 0.91
PDF008 5/16" 7.9 18 37 23 69 0.91
PDF010 3/8" 9.5 20 45 22.5 67.5 0.85
PDF013 1/2" 12.7 23 51 20 60 0.83
PDF016 5/8" 15.9 27 62 18 54 0.81
PDF019 3/4" 19 30.5 76 16.5 49.5 0.72
PDF022 7/8" 22 33 100 14 42 0.45
PDF025 1" 25.4 38 118 12.5 37.5 0.35
PDF032 1-1/4" 32 46 180 10 30 0.14

50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing

50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing

Packaging & Shipping

50m/Roll Double Polyester Fiber Braid Reinforced Silicone Hose 3/16 Id Silicone Tubing

FAQ

1. Are you manufacture?

We started business from trading, but now we have invested and holded several factory in china.

2. Can you ship to my country?

We can ship to all the countries around the world by air or sea.

3. How much is the shipping charge to my country?

It depends on your country located and the weight of goods.

4. What's the price term?

EXW, FOB, CIF, CFR

5. What's your payment?

T/T, L/C, Western Union
