High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates
Specifications
Brand Name :
TONGMAO
Model Number :
steel plate
Certification :
ISO9001 MTC
Place of Origin :
China
MOQ :
10tons
Price :
Negotiablle
Payment Terms :
L/C, T/T
Supply Ability :
500tons/month
Delivery Time :
7-15days
Packaging Details :
Standard Packing
Standard :
ASTM,AISI,JIS,GB,DIN
Length :
1-12m
Grade :
400 Weldox700 Domex500 Nm360
Width :
100-300cm or customized
Thickness :
3mm-100mm
Name :
abrasion resistant steel plate
Description

High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates

Standard Grade DIN : XAR300, XAR400, XAR450, XAR500, XAR600, X120Mn12; 1.3401, etc...
SSAB : WELDOX700, WELDOX900, WELDOX960, etc.
NF : FORA400, FORA500; Creusabro4800, Creusabro8000, etc.
EN : QUARD400, QUARD450, QUARD500; RAEX320, RAEX400, RAEX500, etc.
JIS : JFE-EH360, JFE-EH400, JFE-EH500; WEL-HARD400, WEL-HARD500,etc.
GB : NM360, NM400, NM450, NM500, NM550, NM600, etc.

1.Wear resistant steel plate has high wear resistance and good impact performance. It can be cut, bent and welded. It can be connected with other structures by welding, plug welding and bolt connection. It is time-saving and convenient in the process of maintenance. It is widely used in metallurgy, coal, cement, electric power, glass, mining, building materials, brick and tile and other industries.

Standard Grade C Mn Si Cr Mo Yield strength min Tensile strength min Elongation%
GB/Nm360 Nm360 ≤0.25 ≤1.30 ≤0.70 ≤1.4 ≤0.50 1000MPa 1100MPa 50
AISI GB JIS DIN KS BSEN
Nm360 Nm360 JFE-EH360 DILLIDUR 400V 400 creusabro 4000

2. 400 is a wear-resistant steel plate with a Brinell hardness of 400HB, which has good cold bendability and is mainly used in anti-wear conditions. 400 has very good weldability.
400 wear-resistant steel application: crusher, sieve plate, feeder, feeding funnel, elevator, blade plate, conveyor, bucket, cutter plate, gear, dump truck, scraper, industrial Trucks, rail wagons, bulldozers, excavators. Slurry pipes, screw conveyors, presses, etc.

Country AR Sweden China Germany
Standard AR GB/T XAR
Grade AR400 400 NM400 XAR400
Grade C Si Mn≤ P≤ S≤ Cr≤ Mo≤ Ni≤
AR400 0.12-0.16 0.35-0.55 1.55 0.025 0.005 0.55 0.55 1.0
NM400 0.20 0.70 1.6 0.025 0.01 1.4 0.5 1.0

3.Features of DOMEX700 high-strength steel plate:

The welding performance is similar to that of ordinary low carbon steel. The welding wire used is completely different from ordinary welding wire depending on the material. For equal toughness fit, the strength is slightly lower than that of the base metal.

DOMEX700 does not need special measures such as preheating before welding.

Almost forgot the biggest advantage, the yield strength is 700, choose it in the board below 10mm.

The actual machining experience is harder than ordinary steel.

Standard
JIS, AiSi, ASTM, GB, DIN, EN
Length
1000mm-custom
Width
500-3000mm-custom
Model Number
550/500/450/400/360 NM600/500/450/400/360 Ar500/550/400 Xar500/450/400/550 Dillidur500/450/400
Surfacing composite wear resistant steel plate 4+2 6+2 8+2 3+3 4+4 5+5 6+6 7+7 8+8 10+10
Surfacing composite wear resistant steel plate:Support customization
Certification
ISO
Tolerance
±0.01%
Processing Service
Bending, Welding, Decoiling, Punching, Cutting
Price Term:
CIF CFR FOB EX-WORK
MOQ:
1 TON
Payment terms: TT 30% and the remaining 70% will be paid before delivery.

High Strength Steel Plate 400 Weldox700 Domex500 Nm360 Wear Resistance Sheet Hot Rolled Wear Plates

FAQ

Can you send products to my country?

Sure, we can. If you do not have your own ship forwarder, we can help you.

Will you delivery the goods on time?
Yes,we promise to provide best quality products and delivery on time no matter if the price change lot or not.Honesty is our company's tenet.

How can I get a quotation from you ?
You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
And you can also find our contact information on contact page.

How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them
