Specifications
Brand Name :
Tongmao
Model Number :
Seamless Copper Pipe
Certification :
IS9001
Place of Origin :
China
MOQ :
3 Tons
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 Tons - 1 Month
Delivery Time :
5-15 Working Days
Packaging Details :
Sea Worth Packaging or Client's Request
Name :
Seamless Copper Pipe
Standard :
ASTM, JIS, AISI, EN, GB, DIN, API, BS, CE, ISO
Grade :
C10200, C10300, C10800, C12000, C12200
Application :
Aviation, Aerospace, Ships, Military Industry, Metallurgy, Electronics, Electrical, Mechanical, Transportation, Construction And Other Fields Of The National Economy
Length :
1000mm ~ 12000mm
Specification :
OD 6-130mm
Description

Seamless Copper Tube ASTM Uns C10100 Red Copper Tubing Seamless Copper Round Tube

Product Description

seamless copper tube ASTM UNS C10100 Red copper Tubing seamless Copper round tube

ASTM UNS C10100 99.99 Oxygen Free 5 ppm Copper Sheet

COPPER SHEET / COPPER PLATE Specification and Size

1 Item Copper Tube/Copper Pipe / Brass Tube / Brass Pipe
2 Standard ASTM,DIN,EN,ISO,JIS,GB
3 Material T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,
C10910,C10920,TP1,TP2,C10930,C11000,C11300,C11400,C11500,
C11600,C12000,C12200,C12300,TU1,TU2,C12500,C14200,C14420,
C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,
C26000,C27000,C27400,C28000,C33000,C33200,C37000,C44300,
C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600,
C70620,C71000,C71500,C71520,C71640,C72200,etc.
4 SHAPE Round, square, rectangular, etc.
5 SPECIFICATION Round Wall thickness: 0.2mm~120mm
Square Wall thickness: 0.2mm~120mm
Rectangular Wall thickness: 0.2mm~910mm
6 Length 3m,5.8m, 6m, 11.8m, 12m, or as required.
7 Hardness 1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
8 Surface mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required.
9 Price Term Ex-work, FOB, CFR, CIF, etc.
10 Payment Term T/T, L/C, Western Union, etc.
11 Delivery Time According to order's quantity.
12 Package Export standard package: bundled wooden box, suit for all kinds of transport,
or be required.
13 Export to Singapore,Indonesia,Ukraine,Korea,Thailand, Vietnam, Saudi Arabia,
Brazil, Spain, Canada, USA, Egypt, India, Kuwait, Dubai, Oman, Kuwait,
Peru, Mexico, Iraq,Russia,Malaysia, etc.
14 Application Copper pipe is the first choice of residential housing water pipes, heating, cooling pipes installed.
Copper products are widely used in aviation, aerospace, ships, military industry, metallurgy, electronics, electrical, mechanical, transportation, construction and other fields of the national economy.
15 Copper tube synonyms Copper OFC, Oxygen-free Copper, Copper OFHC, Oxygen-free high thermal conductivity copper, Copper OFE, Oxygen free electrolytic copper, Oxygen Free Electronic Copper, ASTM F68, Copper Alloy 101, C101, C102, C10100, C10200 Copper O, High-conductivity copper, C-110, C11000, C110 Electrolytic Tough Pitch (ETP) copper, Cu-ETP, C122, C-122, C145, C-145, C147, C-147, O60 (soft / annealed) temper, H00 (cold rolled), H01 (cold rolled, high yield), H02 (half hard) temper, H03 (three quarter hard) temper, H04 (full hard) temper

COPPER TUBE / COPPER PIPE PRODUT SHOWCASE

ASTM Uns C10100 Red Copper Tubing Seamless Copper Round Tube

Cu materials/alloys
European standard DIN standard (former) ASTM Typical properties/application Manufacturing standard
Cu-ETP CW004A E-Cu 58 2.0065 C11000 standard alloy for electrical components, main appli- DIN EN 13599
E-Cu 57 2.0060 cation in switchgear construction DIN EN 1652
Cu-HCP Cu-PHC CW021A CW020A SE-Cu 2.0070 C10300 hydrogen-resistant, very high conductivity, easy to weld DIN EN 13599
Cu-OF CW008A OF-Cu 2.0040 C10200 hydrogen-resistant, very high conductivity, very easy to weld DIN EN 13599
Cu-OFE CW009A C10100 high purity, Cu 99.99% fur vacuum switching systems, targets DIN EN 13604
Cu-DHP CW024A SF-Cu 2.0090 C12200 very easy to weld, without particular conductivity requirements DIN EN 1652
DIN EN 1653 AD-2000W6/2
CuAg0,10P CW016A CuAg0,1P 2.1191 C10700 mould plates, commutator rings, electrodes DIN EN 13599
CuCrZr CW106 CuCrZr 2.1293 C18150 mould plates, welding equipment, furnace and mould engineering, heavy current engineering DIN 17670
CuNi2Si CW111C CuNi2Si 2.0855 C18000 mould engineering, machine parts, die casting equipment by arrangement
Products can be supplied by arrangement in compliance with other international standards such as BS, JIS and GOST.

Package and Transportation

ASTM Uns C10100 Red Copper Tubing Seamless Copper Round Tube
