Ss400 S235jr S355jr A53 A36 4X8 Hot Rolled Carbon Ms Mild Steel Sheet Plate
Ss400 S235jr S355jr A53 A36 4X8 Hot Rolled Carbon Ms Mild Steel Sheet Plate
Specifications
Brand Name :
Tongmao
Model Number :
Carbon Steel Sheet Plate
Certification :
ISO9001
Place of Origin :
China
MOQ :
3 Tons
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 Tons - 1 Month
Delivery Time :
5-15 Working Days
Packaging Details :
Sea Worth Packaging or Client's Request
Model NO. :
S235jr
Length :
2~6m
Thinkness :
0.5mm-4mm
Special Use :
Cutting Tools, Cutters in Common Steel
Type :
Steel Plate,Steel sheet
Edge :
Mill Edge
Description

Ss400 S235jr S355jr A53 A36 4X8 Hot Rolled Carbon Ms Mild Steel Sheet Plate

Products Corten Steel Plate
Standard
grade		 ASTM: Corten A; Corten B; A588Gr.A/Gr.B/Gr.C/ Gr.K; A242; A606 Type 4;
A709 Gr 50W;
EN10025: S235J0W; S235J2W; S355J0W; S355J2W; S355K2W; S355J0WP;
S355J2WP; S355J2G1W; S355J2G2W; S355K2G1W, S355K2G2W;
JIS G3114: SMA400AW; SMA400BW; SMA400CW; SMA490AW; SMA490BW;
SMA490CW; SMA570W; SMA570P;
JIS G3125: SPA-H; SPA-C;
GB/T 4171: Q235NH; Q265GNH; Q310GNH; Q295NH; Q295GNH; Q355NH;Q355GNH;
Q415NH; Q460NH; 1500NH; Q550NH;
TB/T 1979: 09CuPCrNi-A; 09CuCrNi-B; 05CuPCrNi;
Q/BQB 340: B460NQR; B490NQR; B480GNQR; B600GNQR;
Thickness Cold Rolled 0.5-2mm Hot Rolled 2-300mm (2-100mm usually used)
Width 1000-3000mm (1000-2200mm usually used)
Length 1000-12000mm or as your request
Surface Clean, finishing,blasting and painting according to customer requirement
Process Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T,
and other delivery states are available as required
Certificate API,ISO,SGS,BV,CE etc
Quality MTC will be provided with goods, third part inspection is acceptable,
for example BV,SGS.
Package Standard export seaworthy package,suit for all kinds of transport,or as required.
Container Size 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
Trade term Ex-Work,FOB,CNF,CFR,CIF,etc
Application Widely used in a variety of architectural and engineering structures,such as
1.) metal constructions such as buildings,bridges,ships;
2.) transmission tower, reaction tower;
3.) lifting transportation machinery;
4.) industrial furnace;boilers
5.) container frame, warehouse goods shelves, etc

Grade and chemical composition of high quality carbon structural steel:

Item code Grade chemical composition(%)
C Si Mn Cr M Cu
≤
1 U20080 08F O.05～O.11 ≤0.03 0.25～0.50 0.10 O.30 0.25
2 U20100 10F O.07～O.13 ≤O.07 O.25～O.50 O.15 0.30 0.25
3 U20150 15F 0.12～O.18 ≤O.07 0.25～O.50 0.25 0.30 0.25
4 U20082 08 0.05～O.11 O.17～O.37 O.35～O.65 O.10 O.30 O.25
5 U20102 1O 0.07～O.13 0.17～O.37 0.35～0.65 0.15 O.30 O.25
6 U20152 15 O.12～0.18 0.17～O.37 O.35～0.65 O.25 O.30 O.25
7 U20202 20 O.17～0.23 0.17～0.37 0.35～0.65 O.25 O.30 O.25
8 U20252 25 O.22～0.29 0.17～O.37 O.50～O.80 O.25 O.30 0.25
9 U20302 30 O.27～O.34 O.17～O.37 O.50～O.80 0.25 O.30 0.25
10 U20352 35 O.32～0.39 O.17～O.37 O.50～O.B0 0.25 O.30 0.25
11 U20402 40 0.37～O.44 0.17～O.37 O.50～O.80 O.25 O.30 O.25
12 U20452 45 O.42_O.50 O.17～O.37 0.50～0.80 0.25 O.30 0.25
13 U20502 50 0.47～0.55 0.17～O.37 0.50～0.80 0.25 O.30 O.25
14 U20552 55 O.52～0.60 O.17～O.37 O.50～0.80 O.25 0.30 O.25
15 U20602 60 0.57～O.65 0.17～O.37 0.50～O.80 O.25 O.30 0.25
16 U20652 65 O.62～0.70 0.17～0.37 O.50～O.80 O.25 O.30 O.25
17 U20702 70 O.67～0.75 0.17～0.37 O.50～O.80 0.25 O.30 O.25
18 U20752 75 O.72～0.80 0.17～O.37 0.50～0.80 0.25 O.30 O.25
19 U20802 80 O.77～0.85 O.17～0.37 O.50～O.80 0.25 O.30 0.25
20 U20852 85 O.82～0.90 O.17～0.37 0.50～O.80 O.25 O.30 O.25
21 U21152 15№ O.12～O.18 O.17～O.37 O.70～1.00 O.25 O.30 0.25
22 U21202 20Mn 0.17～O.23 O.17～O.37 O.70～1.00 O.25 0.30 O.25
23 U21252 25Mn O.22～O.29 0.17～0.37 O.70～1.00 O.25 O.30 O.25
24 U21302 30Mn 0.27～O.34 O.17～0.37 0.70～1.00 O.25 O.30 0.25
25 U21352 35Mn O.32～O.39 O.17～O.37 O.70～1.00 0.25 O.30 O.25
26 U21402 40Mn O.37～0.44 O.17～0.37 O.70～1.00 0.25 0.30 O.25
27 U21452 45Mn 0.42～0.50 0.17～O.37 0.70～1.00 O.25 O.30 O.25
28 U21502 50Mn O.48～0.56 O.17～O.37 O.70～1.00 0.25 0.30 0.25
29 U21602 60Mn 0.57～0.65 O.17～O.37 0.70～1.00 0.25 0.30 0.25
30 U21652 65Mn 0.62～0.70 0.17～O.37 O.90～1.20 O.25 0.30 0.25
31 U21702 70Mn 0.67～O.75 0.17～0.37 0.90～1.20 O.25 O.30 O.25

S235JR steel plate

S235JR steel plate is the European standard non-alloy structural steel, equivalent to the NATIONAL standard Q235B, that is, the carbon structure steel with low carbon content, used for welding, bolt connection, riveting structure more.

S235JR steel plate chemical composition:

C % : 0.17-0.19;

Mn % : 0.14-0.15;

0.035 0.045; P % :

% S: 0.035-0.045;

N %, 0.012-0.14;

Cu % : 0.40-0.45;
S235JR steel plate application analysis:

With good plasticity, toughness, weldability, cold stamping performance and a certain strength, good cold bending performance. Low temperature performance is not good (impact test is 20℃). Widely used for general requirements of parts and welded structural parts. Such as the force is not big pull rod, connecting rod, pin, shaft, screw, nut, ring, bracket, frame, building structure, bridge, etc.

Ss400 S235jr S355jr A53 A36 4X8 Hot Rolled Carbon Ms Mild Steel Sheet Plate
