Specifications
Brand Name :
Sussman
Model Number :
SS-PUSP
Certification :
CE
Place of Origin :
Wuxi Jiangsu China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T L/C
Supply Ability :
10 sets per months
Delivery Time :
90-120 days after deposit
Packaging Details :
Standard packing
Hot air motor :
18.5Kw
Hot air heater :
200Kw
Temperature of double belt :
300-800C
Effective working length :
24m(customized)
Core Density :
40-42 Kg/m2
Thickness of a panel :
40mm-250mm
Description



Technical Parameter

Length of panel: 6m,12m,15m

Width of panel: 500-1250mm

Thickness of panel: 40mm-250mm

Speed of Production line: 8m/min ( frequency conversion to adjust speed )

Core Density (Kg/m2):40-42

Thermal Conductivity (W/m°K):0.018 – 0.020

Tensile Strength (KP a) :300–500

Bending Strength (KP a): 550–560

Shear Strength (KP a):120–300

Modulus of Elasticity (Mp a):3.0 – 8.5

Water Absorption :<2(Volume change %)

Water Vapor Transmission :1.8-3.8(Perm-in)

Stable Operating Temperature:-40to+50(°c)





One set of 6m PU Sandwich panel line is 288 sq.m. per day, 8 hours, so



it is 72000 sq.m. yearly with 2500 days per year



One set of 12m PU sandwich panel line is 576 sq.m. per day, 8 hours. so



it is 14400 sq.m. yearly, for 250 days per year.



Production capacity of this production line: 3-8m/min.



Panel width: 800-1000mm, panel thickness: 30-150mm.



Total power: about 150kw
