0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min
0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min
0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min
0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min
Specifications
Brand Name :
Sussman
Model Number :
RF-ST
Certification :
CE, SGS, ISO
Place of Origin :
Wuxi, China
MOQ :
1 set
Price :
negotiable
Supply Ability :
10 sets/month
Delivery Time :
60 days after deposit
Packaging Details :
Film and steel
Material :
galvanized steel coils
material thickness :
0.8-3mm
coil palte width :
1250mm
slitting speed :
0-40m/min
Description

(0.8-3)x1250 Simple Hydraulic Slitting Line Slitting Speed 0-40m/min

1. Technical Parameter

1. Material of processible coiled plate: galvanized steel coils, etc

2. Thickness of coiled plate 0.8—3mm;

3. Width of coiled plate 1250mm;

4. Precision of slitting width tolerance: ±0. 5mm;

5. Slitting speed: 0—40m/min;

6. Loading capacity of de-coiler machine (feeding machine): 8T;

7. Coil I.D: 508mm;

8. Coil O.D: 1400mm;

9. Knife pivot diameter of slitting blade: Ф200mm; material 40Cr;

10. Slitting blade: Ф180×Ф320×15;

11. Material of slitting blade: 6CrW2Si;

12. Hardness of blade: HRC60°—62°;

13. Recoiler I.D: 508mm;

14. Power: 380V three-phase electricity: 50Hz;

2. Composed Device

1. Hydraulic entry coil car

2. Hydraulic de-coiler

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

3. Hydraulic Pinch And Press Device

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

4. Head Cutting Machine

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

5. Slitting Machine

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

6. Scrap Winder

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

7. Pit

8. Tension Stand

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

9. Hydraulic recoiler

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min

10. Hydraulic unload car

0.8 Mm-3 Mm X 1250 Mm Simple Hydraulic Slitting Line With Speed 0-40m/Min
