Specifications
Place of Origin :
CHINA, JAPAN, THAILAND, UK, USA
Brand Name :
YUHONG SPECIAL STEEL
Certification :
API, PED,
MOQ :
1PC
Price :
NEGITABLE
Packaging Details :
PLY-WOODEN CASE OR PALLET
Delivery Time :
5DAYS
Payment Terms :
T/T, L/C
Supply Ability :
200 TONS PER MONTH
Model Number :
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Material :
Copper alloy bush,Duplex steel bush,Stainless steel bush,Alloy steel bush,Carbon steel bush
Standards :
ASTM / ASME SB 564 / 160 / 472
Size :
1/2"NB to 4"NB IN
Class :
3000 LBS, 6000 LBS, 9000 LBS
Type :
Socket Weld (S/W) & screwed (SCRD) - NPT, BSP, BSPT
Description

ASME Forged Steel Fittings / Class 9000 Screwed Hex Bush

Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)

Hex Bush

We provide our clients’ precision designed range of hex bush fittings that are known for their tolerance for temperature and durability. These are assured of quality, and the standing testimony for the same is their mill test certificate as per EN 10204 / 3.1B. We are offering these hex bushes at market leading prices.

Specifications:

  • Size: 1/2"NB to 4"NB IN

  • Class: 3000 LBS, 6000 LBS, 9000 LBS

  • Type: Socket Weld (S/W) & screwed (SCRD) - NPT, BSP, BSPT

Standards:

  • ASTM / ASME SB 564 / 160 / 472

  • UNS 10276 (HASTELLOY C 276 bushing)

  • UNS 2200 (NICKEL 200 bushing)

  • UNS 2201 (NICKEL 201 bushing)

  • UNS 4400 (MONEL 400 bushing)

  • UNS 8020 (ALLOY 20 bushing)

  • UNS 8825 (INCONEL 825 bushing)

  • UNS 6600 (INCONEL 600 bushing)

  • UNS 6601 (INCONEL 601 bushing)

  • UNS 6625 (INCONEL 625 bushing)

Material:

Material Standards
Copper alloy bush ASTM / ASME SB 61 / 62 / 151 / 152 C 70600 (CU -NI- 90/10) - Cupro Nickel bushing C 71500 (CU -NI- 70/30) - Copper Nickel bushing UNS NO. C 92200, UNS NO. C 83600, UNS NO. UNS NO C 10100, C 10200, C 10300, C 10800, C 12000, C 12200
Duplex steel bush ASTM / ASME A/SA 182 UNS F 44, F 45, F51, F 53, F 55, F 60, F 61
Stainless steel bush ASTM A182 F304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Alloy steel bush ASTM / ASME A/SA 182 F1/F5/F9/F11/F22/F91
Carbon steel bush ASTMA 105/A694/ Gr. F42/46/52/56/60/65/70
Low temperature carbon steel bush A350 LF3/A350 LF2

Product Pictures and Drawings
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Square Head Plug
Hexagon Plug
Round Head Plug
Hexagon Bushing
Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD) Forged Steel Bush : A-182/A105 S/W & SCRD,B16.11, Class 3000, Class 6000, Class 9000,Socket Weld (S/W) & screwed (SCRD)
Flush Bushing 　
Dimensional Data
　
Nominal Pipe Size 1/8 1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 4
A 1 3/8 1 5/8 1 5/8 1 3/4 1 3/4 2 2 2 2 1/2 2 3/4 2 3/4 3
B 13/32 17/32 11/16 27/32 1 1/16 1 5/16 1 11/16 1 29/32 2 3/8 2 7/8 3 1/2 4 1/2
C* 7/16 5/8 11/16 7/8 1 1/16 1 7/16 1 13/16 2 2 1/2 3 3 3/4 4 5/8
D 1/4 1/4 5/16 5/16 3/8 3/8 9/16 5/8 11/16 3/4 13/16 1 1/4
E 7/16 1/2 9/16 11/16 3/4 27/32 7/8 15/16 1 1 1/4 1 9/16 1 21/32
F 9/32 3/8 7/16 9/16 5/8 13/16 15/16 1 1/8 1 5/16 1 1/2 1 11/16 2 1/2
G 1/4 1/4 5/16 3/8 7/16 1/2 9/16 5/8 11/16 3/4 13/16 1 1/4
H 3/8 7/16 1/2 9/16 5/8 3/4 13/16 13/16 7/8 1 1/16 1 1/8 1 3/8
J* 5/8 11/16 7/8 1 1/16 1 7/16 1 13/16 2 2 1/2 3 3 3/4 4 5/8
K 3/16 3/16 3/16 1/4 1/4 3/8 3/8 3/8 1/2 13/16 1 1/4
L 1/2 9/16 11/16 3/4 27/32 7/8 15/16 1 1 1/4 1 9/16 1 21/32
M 7/16 1/2 9/16 5/8 3/4 13/16 13/16 7/8 1 1/16 1 1/8 1 1/4
N 3/8 7/16 1/2 9/16 5/8 3/4 13/16 13/16 7/8 1 1/16 1 1/8 1 1/4
*Dimension J for Hex Head Bushing and dimension C for Hex Head Plug are the same.
