Specifications
Brand Name :
YUHONG
Model Number :
TP304H / UNS S30409 / 1.4948
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
100 KG
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According to Client Requirements
Delivery Time :
15-35 DAYS
Packaging Details :
According to Client Requirements/Wooden Case Packing/Woven Bag Packing
Standard :
ASTM A312 / ASME SA312
Material Grade :
TP304H, UNS S30409
Type :
Seamless
Outer diameter :
6mm-630mm or Customized
Thickness :
1mm-60mm
Length :
6 Meters Or Customized
DNT :
ET,UT,PT,HT
Applications :
Decoration,Construction,Boiler,Oil and Gas,Electric
Description

ASTM A312 TP304H(UNS S30409) Stainless Steel Seamless Pipe For Chemical Industry

YUHONG GROUP is one of the well-known manufacturers and suppliers in China. We have exported stainless / duplex / nickel alloy steel tubes and pipes to more than 60 countries, and we gradually become a reliable partner to our clients. Stainless steel seamless pipes are used in a variety of applications, like petrochemical plants, marine euipments, water treatment systems, food processing equipments, offshore plants, and so on.

Size Range:

STEEL TYPES SIZE RANGE
Stainless steel seamless pipe&tube OD: 6-609.6mm WT: 0.6-50mm

Steel Grade:

PRODUCTS TYPICAL STEEL GRADE
Austenitic

TP304,TP304L,TP304H,TP316,TP316L,TP316H,TP316Ti

TP321,TP321H,TP347H,904L,TP310H,TP310S,TP317,TP317L
Duplex / Super Duplex S31803, S32205, S32750, S32760, S31500, S32304, S31254
Nickel Alloy

Incoloy800, Incoloy800H, Incoloy800HT, Incoloy825, Incoloy926

Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718

Monel 400, K500,

Hastelloy C276 , G-3.

Nickel 200 ,

UNS NO8028 , UNS NO8535, UNS NO8135, UNS NO6985, UNS NO6950

Standards:

Standard Type Standard
EN EN10216-5 , EN10216-2
DIN DIN 17456 , DIN 17458
ASTM ASTM A312, A213, A269, A511, A789, A790 etc
GOST GOST 9941 , GOST 5632
JIS JIS G3459 , JIS G3463
GB GB/T14975,GB/T14975, GB13296, GB5310, GB9948

Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.


Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.


MTC: BWSS Official Original MTC paper will be supplied for each order.

Quality Control:

Corrosion Test Conducted only when specially requested by the client
Chemical Analysis Test done as per required quality standards
Destructive / Mechanical Testing Tensile | Hardness | Flattening | Flare | Flange
Reverse-bend and Re. flat tests Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end
Eddy Current Testing Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System
Hydrostatic Testing 100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s .
Air Under Pressure Test To check any evidence of air leakage
Visual Inspection After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections

ASTM A312 TP304H(UNS S30409) Stainless Steel Seamless Pipe For Chemical Industry
