Specifications
Brand Name :
YUHONG
Model Number :
ASTM B366 Hastelloy C276 Elbow
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
1PC
Price :
negotiation
Supply Ability :
200 TONS PER MONTH
Delivery Time :
according to quantity
Packaging Details :
Plywood case/Pallet
Payment Terms :
T/T, L/C
Standrad :
ASTM B366; ASME SB366
Material :
UNS N10276; Hastelloy C276
Type :
Hastelloy Steel Buttweld Elbow
Degree :
45/90/180
Radius :
Long Radius/Short Radius
Sizes :
1/2''-48''(DN15-DN1200) or custom size
Thickness :
SCH10S-XXS
Surface :
Sand Blasting
Description

ASTM B366 UNS N10276 / Hastelloy C276 Elbow Hastelloy Steel Buttweld Fitting

Overview:

Hastelloy C276 is a nickel-molybdenum-chromium alloy with excellent corrosion resistance in a wide range of aggressive environments. An elbow, in the context of piping and plumbing, is a pipe fitting that changes the direction of the flow. A Hastelloy C276 elbow, therefore, is a specialized pipe fitting made from this particular alloy.

The Hastelloy C276 elbow is specifically designed for use in corrosive environments where superior resistance to both oxidizing and reducing media is required. This makes it an ideal choice for applications in chemical processing, pollution control, pulp and paper production, industrial waste treatment, and many other industries where corrosion resistance is critical.

Due to its unique chemical composition, including high levels of nickel, molybdenum, and chromium, Hastelloy C276 offers exceptional resistance to a variety of corrosive agents such as sulfuric acid, hydrochloric acid, phosphoric acid, chlorine, and seawater, among others.

The elbow shape allows for a change in the direction of fluid flow, and by utilizing Hastelloy C276, the elbow can maintain its structural integrity and corrosion resistance even in demanding operating conditions.

It's important to note that Hastelloy C276 is known for its versatility and reliability in high-stress environments, and as such, Hastelloy C276 elbows are highly regarded for their performance and longevity in challenging industrial settings.

Specification:

Standard ASTM B366 & Its equivalent ASME, DIN & EN Standard.
Grades UNS N10276
Size 1/2''-48'' or custom size
Wall Thickness SCH10S to SCH.XXS
Radius SR LR
End Beveled End
Surface Sand Blasting
Packing Plywood case/Pallet

Grade Ni Cr Mo Fe W C Si Co Mn V P S
UNS N10276 Remainder 14.5-16.5 15.0-17.0 4.0-7.0 3.0-4.5 0.01 max 0.08 max 2.5 max 1.0 max 0.35 max 0.04 max 0.03 max

Grade Tensile Strength, min, ksi (MPa) Yield Strength,
min, ksi (MPa)		 Elongation in 2 in.
or 50mm, min (%)
UNS N10276 100(690) 41(283) 40

Dimension:

ASTM B366 UNS N10276 / Hastelloy C276 Elbow Hastelloy Steel Buttweld Fitting ASTM B366 UNS N10276 / Hastelloy C276 Elbow Hastelloy Steel Buttweld Fitting
Nominal Size

Outside Diameter at Bevel

(mm)

Center to End

(mm)
90° Elbow 45° Elbow
DN NPS O.D. A B
LR SR LR
15 1/2 21.3 38 ... 16
20 3/4 26.7 38 ... 19
25 1 33.4 38 25 22
32 1 1/4 42.2 48 32 25
40 1 1/2 48.3 57 38 29
50 2 60.3 76 51 35
65 2 1/2 73.0 95 64 44
80 3 88.9 114 76 51
90 3 1/2 101.6 133 89 57
100 4 114.3 152 102 64
125 5 141.3 190 127 79
150 6 168.3 229 152 95
200 8 219.1 305 203 127
250 10 273.0 381 254 159
300 12 323.8 457 305 190
350 14 355.6 533 356 222
400 16 406.4 610 406 254
450 18 457.0 686 457 286
500 20 508.0 762 508 318
550 22 559.0 838 559 343
600 24 610.0 914 610 381
650 26 660.0 991 660 406
700 28 711.0 1067 711 438
750 30 762.0 1143 762 470
800 32 813.0 1219 813 502
850 34 864.0 1295 864 533
900 36 914.0 1372 914 565
950 38 965.0 1448 965 600
1000 40 1016.0 1524 1016 632
1050 42 1067.0 1600 1067 660
1100 44 1118.0 1676 1118 695
1150 46 1168.0 1753 1168 727
1200 48 1219.0 1829 1219 759
Notes:
1) Besides these, GB/T 10752, SH 3408, SH 3409, HG/T 21635, HG/T 21631, SY/T 0510, DL/T 695, EN 10253 etc.are also applied.
2) The elbow with NPS over 48 shall be made subject to the sizes agreed by purchaser and manufacturer.
