ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A234 WPB-S LR/SR 90DEG ELBOW
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015, IEI
Place of Origin :
CHINA
MOQ :
1PC
Price :
discussion
Supply Ability :
200 TONS PER MONTH
Delivery Time :
according to quantity
Packaging Details :
Ply-wooden Case Or Iron Case
Payment Terms :
T/T, L/C
Standard :
ASTM A234
Grade :
WPB-S
Material :
Carbon Steel
Type :
Elbow
Size :
Customized Size
Degree :
45 90 180
Description

ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SMLS/WELD B16.9

Overview

Steel elbow is used to be installed between two lengths of pipe or tube allowing a change of direction,usually these carbon steel elbows distinguished by connection ends, The ends may be machined for butt welding , threaded or socketed, so the carbon steel elbows are consist of butt weld,thread elbow socket elbow and other series.the material is selected according to the application use such as high temperature use,sanitary fitting,regular industrial use etc.


Specfication

Product Name

Pipe elbow

Size

1/2"-36" seamless, 26"-110" welded

Standard

ANSI B16.9, EN10253-2, DIN2605, GOST17375-2001, JIS B2313, MSS SP 75, etc.

Wall thickness

STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc.

Elbow

30° 45° 60° 90° 180°,etc

Radius

LR/long radius/R=1.5D,SR/Shrot radius/R=1D

End

Bevel end/BE/buttweld

Surface

nature color, varnished, black painting, anti-rust oil etc.

Material

Carbon steel: A234WPB, A420 WPL6 St37,St45, E24, A42CP, 16Mn, Q345, P245GH,P235GH, P265GH, P280GH, P295GH, P355GH etc.

Pipeline steel: ASTM 1860 WPHY42, WPHY52, WPHY60, WPHY65,WPHY70, WPHY80 and etc.

Cr-Mo alloy steel: A234 WP11,WP22,WP5,WP9,WP91, 10CrMo9-10, 16Mo3 etc.

Advantages

ready stock,faster delivery time;available in all sizes,austomized;high quality

Chemical Composition

Grade

C

Mn

P

S

Si

Cr

Mo

Ni

Cu

V

Nb

WPB

0.3

0.29-1.06

0.05

0.058

0.1min

0.4

0.15

0.4

0.4

0.08

0.02

Mechanical Properties

Tensile Requirements

WPB

WPC, WP11CL2

WP11CL1

WP11CL3

Tensile Strength, min, ksi[MPa]

60-85

70-95

60-85

75-100

(0.2% offset or 0.5% extension-under-load)

[415-585]

[485-655]

[415-585]

[520-690]

Yield Strength, min, ksi[MPa]

32

40

30

45

[240]

[275]

[205]

[310]


Applications

1. Petrochemical Industry

2. Aviation and Aerospace Industry

3. Pharmaceutical Industry

4. Gas Exhaust

5. Power Plant

6. Ship Building

7. Water Treatment

ASTM A234 WPB-S, CARBON STEEL PIPE FITTING, 90DEG ELBOW LR/SR SEAMLESS/WELD B16.9
