Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
Specifications
Brand Name :
YUHONG
Model Number :
F310, UNS S31000
Place of Origin :
China
MOQ :
3 Pieces
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According to Clients' Requirement
Delivery Time :
5 - 90 Work Days
Packaging Details :
Ply-wooden Case / Pallet
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Standard :
ASTM A182, ASME SA182
Material Grade :
F310, UNS S31000
Size :
1/2"-24"
Pressure :
Class150/300/600/9001500/2500
Type :
Threaded flange,Slip on Flange,socket weld flange,weld neck flange,LAP Joint Flange
Technics :
Froged
Surface treatment :
Heat treatment,Galvanized,pickeling
Application :
Petroleum,chemical,fittings and connection,beer
Description

Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5

Stainless Steel 310 is the combination of nickel and chromium giving them resistant to general corrosion. Due to the content of nickel in the alloy, These flanges have good strength at the most extreme weather conditions and also have excellent resistance to the creep deformation. ASTM A182 F310 Stainless Steel Flange combines excellent high temperature properties with good ductility and weldability. It is designed for high temperature service. ASTM A182 F310 Flanges is widely used for applications in the industrial, architectural, and transportation fields.

Equivalent Grades:

STANDARD UNS JIS GOST WERKSTOFF NR. BS EN
SS310 S31000 SUS 310 20Ch25N20S2 1.4841 310S24 X15CrNi25-20

Specifications:

Specifications ASTM A182, ASME SA182
Flange size range 1/2” to 24”
Flanges Dimensions ANSI/ ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Flanges Standard ANSI, AWWA, ASME, BS 10 Table D Flanges, Table E Flanges, BS, DIN, EN, GOST.
Class 150#, 300#, 600#, 900#, 1500#, 2500#
Flange Connect Type/ Flange Face Type Raised Face (RF), Ring Type Joint (RTJ), Large Male-Female (LMF), Flat Face (FF), Small Male-Female (SMF), Lap-Joint Face (LJF), Small Tongue, Large Tongue & Groove
Specialized manufacturer of Weld Neck Ring Flanges (WNRF), Slip-On Ring Flanges (SORF), Blind Ring Flanges (BLRF), Socket Weld Ring Flanges (SWRF), Lap Joint Ring Flanges (LJRF), Ring Type Joint Flanges (RTJF), Large Diameter Flanges, Orifice Flanges

Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5

Chemical Composition:

Ni 19– 21
Cr 24 – 26
C 0.015 max
Mn 2 max
P 0.02 max
S 0.015 max
Si 0.15 max
Mo 0.1 max
Fe 54.7 min

Mechanical Properties:

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
7900 kg/m3 1402 °C (2555 °F) 75000Psi, 515Mpa 30000Psi, 205Mpa 40 %

Applications:

Chemical Industries

Petrochemical Industries

Gas Processing Equipments

Power Generation

Sugar Industries

Food Processing Equipments

Waterworks Systems

Stainless Steel Flanges ASTM A182 F310, UNS S31000 Weld Neck RTJ Flange B16.5
