Specifications
Brand Name :
YUHONG GROUP
Model Number :
TP317L
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
1PC
Price :
Negotiation
Payment Terms :
L/C at sight , T/T
Supply Ability :
10000 Ton/month
Delivery Time :
Depends on quantity
Packaging Details :
Bundle /Ply-wooden Case
Material Grade :
TP304
Standard :
ASTM A312
Size :
1/8″ – 30″
W.T. :
Sch 5s, Sch 10s, Sch 40s, Sch 80s
Length :
Single Random, Double Random & Required Length
NDT :
ET HT UT PT
Packing :
Ply-wooden Case /Iron Case/ Bundle
Appllication :
petroleum refineries/natural-gas processing/space heating
Description

ASTM A312 TP304 Welded Pipes Boilers automobiles ships construction Heat Exchanger

What is ASTM A312 TP304 ​Welded Pipe?

ASTM A312 TP 304 stainless steel is the most commonly used 300 series stainless steel grade, which combines sufficient chromium and nickel content for excellent performance. ASTM A312 TP 304 has good corrosion resistance, good formability and good weldability for a variety of applications.

Chemical Composition of ASTM A312 TP304 Welded Pipe

Grade C Mn P S Si Ni Cr Fe
TP304 0.08 2.00 0.045 0.030 1.0 8-11 18-20 Bal.

Mechanical Properties of ASTM A312 TP304 Welded Pipe

Tensile Strength(Mpa) Max Yield Point(Mpa) Max Elongation(%) Hardness (HRB) Max
TP304 515 205 35 92

Equivalent of ASTM A312 TP304 Welded Pipe

TP304 stainless steel EN equivalent is 1.4301.

Heat Treatment

All seamless steel tubes should be heat treated at the specified temperature. After cold working, residual stresses and potential impurities may occur, and the heat treatment will rebuild the alloy structure and then obtain the original properties. the minimum annealing temperature for TP304 stainless steel should be 1040 degrees C.

ASTM A312 TP304 Welded Pipe APPLICATION

Boilers

automobiles

ships

construction

Heat Exchanger
