ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
Specifications
Brand Name :
YUHONG
Model Number :
TP304 / UNS S30400 / 1.4301
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
100 KGS
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
According To Clients' Requirements
Delivery Time :
7-60 Days
Packaging Details :
Ply-wooden Case / Pallet
Standard :
ASTM A240 / ASME SA240
Material Grade :
TP304 / UNS S30400 / 1.4301
Type :
coil/strip
Length :
As customer's requests
Technique :
Hot/Cold Rolled
Application :
Construction,Industry,decoration,Automotive
Description

ASTM A240 SS304 /304L Stainless Steel Plate / Sheet / Coil

Description

Stainless Steel 304 Sheet is made up of an austenitic stainless steel that has 18% chromium and 8% nickel in the composition. This is the most used grade of all stainless steels in the world. The sheets are strong, mild corrosion resistant and have applications in a variety of industries. The Stainless Steel 304 Sheet also has manganese, carbon, silicon, sulfur, nitrogen and phosphorus in the composition. The material is strong and has 205MPa minimum yield strength and 515MPa minimum tensile strength in general.

As a widely used steel, it has good corrosion resistance, heat resistance, low temperature strength and mechanical properties; it has good hot workability such as stamping and bending without heat treatment. Hardening phenomenon (use temperature -196℃～800℃). It is resistant to corrosion in the atmosphere.

304 Stainless Steel Plate Melting Point

Grade

Density (kg/m3)

Elastic Modulus (GPa)

Mean Coefficient of Thermal Expansion (μm/m/°C)

Thermal Conductivity (W/m.K)

Specific Heat 0-100°C (J/kg.K)

Electrical Resistivity (nΩ.m)

0-100°C

0-315°C

0-538°C

at 100°C

at 500°C

304/L/H

8000

193

17.2

17.8

18.4

16.2

21.5

500

720

Physical Properties

Grade

Density (kg/m3)

Elastic Modulus (GPa)

Mean Coefficient of Thermal Expansion (μm/m/°C)

Thermal Conductivity (W/m.K)

Specific Heat 0-100°C (J/kg.K)

Electrical Resistivity (nΩ.m)

0-100°C

0-315°C

0-538°C

at 100°C

at 500°C

304/L/H

8000

193

17.2

17.8

18.4

16.2

21.5

500

720

Chemical Properties

Grade

C

Mn

Si

P

S

Cr

Mo

Ni

N

304

min. max.

-

0.08

-

2.0

-

0.75

-

0.045

-

0.030

18.0

20.0

-

8.0

10.5

-

0.10

304H

min. max.

0.04

0.10

-

2.0

-

0.75

-0.045

-

0.030

18.0

20.0

-

8.0

10.5

Mechanical Properties

Grade

Tensile Strength (MPa) min

Yield Strength 0.2% Proof (MPa) min

Elongation (% in 50mm) min

Hardness

Rockwell B (HR B) max

Brinell (HB) max

304

515

205

40

92

201

304H

515

205

40

92

201

Equivalent Chart

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 304 1.4301 S30400 SUS 304 304S31 08Х18Н10 Z7CN18-09 X5CrNi18-10
SS 304L 1.4306 / 1.4307 S30403 SUS 304L 3304S11 03Х18Н11 Z3CN18-10 X2CrNi18-9 / X2CrNi19-11
SS 304H 1.4948 S30409 SUS 304H – – – –

APPLICATION


• Chemical containers
• Heat exchangers
• Petrochemical and petrochemical refining
• Food processing
• Kitchen benches

ASTM A240 SS304 / 304L Stainless Steel Plate / Sheet / Coil
