253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A312 253 MA / UNS S30815 / 1.4835 Stainless Steel Seamless Pipe
Certification :
ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
500KGS
Payment Terms :
L/C, T/T
Delivery Time :
7 DAYS
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Product Name :
Stainless Steel Seamless Pipe
Standard :
ASTM A312 / ASME SA312
Material :
TP304/304L/304H/316L/309S/310S/316L/316H/317H/321/253MA, etc.
O.D. :
1/2''~48''
W.T. :
SCH 5S - XXS
Length :
fixed length, random length
End :
Plain Ends / Beveled Ends
Type :
Seamless / Welded
Surface :
Pickled and Annealed
High Light :
ASTM A312 253 MA Stainless Steel Seamless Pipe
Description

253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe

Grade 253MA provides excellent service properties & ease of fabrication at high temperatures. It provides superior service to Grade 310 in carbon, nitrogen and sulphur containing atmospheres and resists oxidation at temperatures up to 1150°C. 253MA gives some advantage in reducing sulphide atmospheres when compared to high nickel alloys and to Grade 310, due to its fairly low nickel content. 253MA steel provides good oxide stability, high elevated temperature strength and excellent resistance to sigma phase precipitation due to its properties of inclusion of high silicon, nitrogen and cerium. Even down to cryogenic temperatures, the austenitic structure gives this grade excellent toughness.

Equivalent Grades of ASTM A312 253MA SS Pipe

Grade UNS WERKSTOFF NR. EN SS
253MA(UNS S30815) S30815 1.4835 X9CrNiSiNCe21-11-2 2368

Chemical Composition of ASTM A312 253MA SS Pipe

Grade

C

max

Si

max

Mn

max

P

max

S

max

 Cr Ni Mo N
UNS S30815 0.05~0.10 1.4~2.0 0.80 0.030 0.030 20.0-22.0 10.0-12.0 / 0.14-0.20

Physical properties of ASTM A312 253MA SS Pipe

Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (mm/m/°C) Thermal Conductivity (W/m.K) Specific Heat Electrical Resistivity (nW.m)
0-100°C 0-600°C 0-1000°C at 20°C at 1000°C 0-100°C (J/kg.K)
7800 200 17 18.5 19.5 15 29 500 850

Mechanical Properties of ASTM A312 253MA SS Pipe

Tensile Str (MPa) min Yield Str 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
600 310 40 95 217

253MA Stainless Steel Pipe ASTM A312 UNS S30815 / EN 1.4835 Seamless Pipe

Standard Available in forms

• ASTM A182/ ASME SA182 Stainlees Steel Pipe Fittings

• ASTM A213 / ASME SA213 Seamless Stainless Steel Pipes

• ASTM A240/ ASME SA240 Stainless Steels Sheets / Plates

• ASTM A249/ ASME SA249 Stainless Steel Welded Tubes

• ASTM A269/ ASME SA269 Stainless Steel Tubes

• ASTM A270/ ASME SA270 Stainless Steel Sanitary Tubes

• ASTM A312/ ASME SA312 Stainless Steel Pipes

• ASTM A403/ ASME SA403 Stainless Steel Pipe Fittings

• ASTM A554/ ASME SA554 Stainless Steel Welded Tubes

• ASTM A731/ ASME SA731 Stainless Steel Pipes

• ASTM A789/ ASME SA789 Stainless Steel Tubes

• ASTM A790/ ASME SA790 Stainless Steel Pipes

• ASTM A791/ ASME SA791 Stainless Steel Tubes

Apllications

Chemical, Pharmaceutical & Bio-Medical, Petrochemical & Refinery, Environmental, Food Processing, Aviation, Chemical Fertilizer, Sewage Disposal, Desalination, Waste Incineration etc.
