Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
Specifications
Brand Name :
YUHONG
Model Number :
F304
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According To Clients' Request
Delivery Time :
5 - 90 Work Days
Packaging Details :
Ply- Wooden Case/Plastic Bag / Plastic Cap
Standard :
ASTM A182, ASME SA182
Material Grade :
F304
Size :
1/2''-48''(DN15-DN1200)
Class :
class1500/3000/9000
Technics :
Forged
Type :
Elbow,Nipple,Pipe Threaded,Reducer
Connection :
Welding,Female,Male
Application :
Construction,gas and oil pipes,air,Steam,Petroleum gas water
Description

Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11

A182 F304 is a type of stainless steel that is resistant to corrosion and rusting. ASTM A182 F304 Stainless Steel Forged Fittings are widely used to connect two pipes and can be made from a variety of metals, including copper, brass, aluminum, or stainless steel. It is also resistant to heat and has a high level of ductility. F304 Stainless Steel Forged Fitting is one of the most popular industrial products available in the market. SS 304 Forged Fittings and SS 304L Forged Fittings products are ideal for various industrial applications, such as gas pipelines, condensers, and nuclear applications. F304 Stainless Steel Forged Fittings have excellent mechanical properties.

Equivalent Grades:

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 304 1.4301 S30400 SUS 304 304S31 08Х18Н10 Z7CN18‐09 X5CrNi18-10

Specifications ASTM A182, ASME SA182
Dimension ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
End Threaded, Welding, JIC
Pressure Rating Threaded end-2000lb/ 3000lb/ 6000lbs Pipe Fittings
Socket-weld end-3000/ 6000/ 9000lbs Pipe Fittings
Connection Welding
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings
Size Range ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Manufacturing process Push, Press, Forge, Cast, etc.
Types 90º Elbows, 45º Elbows, Tees, Crosses, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows – Female-Female, Male-Female, Male-Male, Union, Nipples, Couplings, Plugs Fittings

Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11

Chemical Composition:

C 0.08 max
Mn 2 max
Si 0.75 max
P 0.045 max
S 0.03 max
Cr 18 – 20
Ni 8 – 11

Mechanical Properties:

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

Application:

Plumbing

Petroleum Industry

Chemical Industries

Oil & Gas Industry

Fabrication Industry

Power Plants

Modern Architecture

Food Processing Industries

Fertilizers Industries

Stainless Steel Fittings, ASTM A182 F304 Socket Weld Forged Elbow ASME B16.11
