Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
Specifications
Brand Name :
YUHONG
Model Number :
F316L
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According to Client's Requirements
Delivery Time :
5 - 90 Work Days
Packaging Details :
Ply-wooden Case / Pallet
Standard :
ASTM A182, ASME SA182
Material Grade :
F316L, UNS S31603
Forming Type :
Elbow,Nipple,Reducer,Eelbow,Tee,Coupling,Etc.
Technics :
Forged
Size :
1/2''-48''(DN15-DN1200)
Class :
1500LBS, 3000LBS, 6000LBS
Type :
Seamless, Welded
Application :
Construction,gas and oil pipes,air,Steam,Petroleum gas water
Description

Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11

ASTM A182 F316L, UNS S31603 Forged Socket Weld Fitting is the low carbon version of 316 and is immune from sensitisation. It is widely used in heavy gauge welded components (over about 6mm). ASTM A182 F316L Stainless Steel Pipe Fittings contain some effective features. They contain the most effective features are high oxidation resistant and excellent pitting resistance. They’re much better corrosion resistance as compared to 304 type stainless steel. And they have strong resistance to the most chemical feature.

Specifications:

Specification ASTM A182, ASME SA182
Dimensions ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size 1/4" to 48"
Type Socketweld Fittings, Threaded / Screwed Fittings
Rating Pressure 2000LBS, 3000LBS, 6000LBS, 9000LBS

Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11

Equivalent Grades:

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 316L 1.4404 / 1.4435 S31603 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3

Chemical Composition:

Grade C Mn Si P S Cr Mo Ni N
F316L 0.035 max 2 max 1 max 0.045 max 0.03 max 16 - 18 2 - 3 10 - 14 68.89 min

Mechanical Properties:

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8 g/cm3 1399 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

Applications:

Plumbing

Construction

Petroleum Industry

Fabrication Industry

Fabrication Industry

Power Plants

Oil & Gas Industry

Forged Fittings ASTM A182 F316L Stainless Steel Threaded Elbows, Couplings, ASME B16.11
