Specifications
Brand Name :
YUHONG
Model Number :
TP430Ti
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
China, USA, Korea, UE
MOQ :
1PC
Price :
negotiable
Payment Terms :
T/T, L/C
Supply Ability :
10000 tons per month
Delivery Time :
Depends on quantity
Packaging Details :
Ply-wooden Case /Bundle
Material Grade :
TP430Ti
Standard :
ASTM A268
Type :
Seamless & Straight & U bend & Coil
NDT :
ET, HT, UT
W.T. :
0.5 mm-12mm
Size :
6.25mm-203mm
Length :
Single Random, Double Random & Cut Length.
Packing :
Ply-wooden Case /Iron Case/ Bundle
Application :
gas/food processing/Chemical
Description

ASTM A268 TP430Ti Ferritic Stainless Steel Tube Petroleum Chemical Condense Heater

YUHONG GROUP deal with seamless steel pipe and tube already more than 33 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 70 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France ...

Chemical Composition of ASTM A268 TP430Ti Stainless Steel Tube

Grade C Si Mn P S Cr Ti Ni
TP430Ti, UNS S43036 0.10 max 1.00 max 1.00 max 0.040 max 0.030 max 25.0~27.5 5XC min, 0.75 max. 0.75 max

Mechanical Properties of A268 TP430Ti Stainless Steel Tube

Tensile strength Mpa, min Yield strength Mpa, min Elongation in 2'' %, min.
415 240 20

Tolerance of A268 TP430Ti Stainless Steel Tube

Outside Diameter, In.[Mm] OD Tolerance, In.[Mm] Wall Thickness, % Thin Wall Tubes
Up To1⁄2, [12.7], Excl ±0.005 [0.13] ±15
1⁄2 To 11⁄2 [12.7 To 38.1], Excl/Td> ±0.005 [0.13] ±10< Less Than 0.065 In. [1.6 Mm] Nominal
11⁄2 To 31⁄2 [38.1 To 88.9], Excl ±0.010 [0.25] ±10 Less Than 0.095 In. [2.4 Mm] Nominal
31⁄2 To 51⁄2 [88.9 To 139.7], Excl ±0.015 [0.38] ±10 Less Than 0.150 In. [3.8 Mm] Nominal
51⁄2 To 8 [139.7 To 203.2], Incl ±0.030 [0.76] ±10 Less Than 0.150 In. [3.8 Mm] Nominal

Characteristics of ASTM A268 TP430Ti Stainless Steel Tube

  • Basic corrosion and oxidation resistance
  • Composition balanced for optimum formability
  • Weldable only in thin sections due to fully ferritic structure
  • Low cost and limited cost variation due to low alloy content

Overwiew:

430Ti is an alternative to 430 with better formability and weldability for stamping, drawing and complex shape applications.
applications and complex shapes. It is a medium chromium ferritic stainless steel that can be used in many lightly corrosive environments.Used in many mildly corrosive environments. Due to its titanium alloying, 430Ti can be welded in all sizes without being susceptible to intergranular corrosion.
430Ti can be used at high temperatures, for example at the cold end of automotive exhaust systems.

Application:

petroleum

chemical

war and electricity industries

food processing

medical industry

machinery

hardware fields.

ASTM A268 TP430Ti Ferritic Stainless Steel Tube Petroleum Chemical Condense Heater
