ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
Specifications
Brand Name :
YUHONG
Model Number :
JIS, AISI, ASTM, GB, DIN, EN
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
500KGS
Price :
Negotiable
Payment Terms :
L/C AT SIGHT, T/T
Supply Ability :
100 tons per month
Delivery Time :
Depends on quantity
Packaging Details :
According to client requirements/wooden case packing
Product Name :
Stainless Steel Flat Bar
Standard :
JIS, AISI, ASTM, GB, DIN, EN
Material :
304, 304L, 304H, 309S, 310S, 316L, etc.
Shape :
Flat
Technique :
Hot rolled, Cold drawn
Package :
Standard Seaworthy Package
Application :
Electric Tower, Bridge Manufacturing, Chemical Engineering, Railway Construction, etc.
High Light :
ASTM A276 TP304 Stainless Steel Flat Bar, ASTM A276 TP304 Stainless Steel Angle Bar
Description

ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm for Industrial Furnace

Stainless steel bars include stainless steel black bars, stainless steel bright bars. stainless steel round bars. stainless steel square bars. stainless steel hexagonal bars. stainless steel special-shaped bars, stainless steel free-cutting bars, etc
The surface of the stainless steel bright rod is bright, that is. the hot-rolled stainless steel black rod is cold-drawn through a cold rolling mill to remove the black color on the surface. Stainless steel bright rods are generally cold drawn. finely ground or polished, with good surface brightness and wide applications.
Stainless steel black bar is our customary name. The proper term is stainless steel hot-rolled bar, which is a stainless steel bar that is hot-rolled Since the stainless steel bar comes out of the hot rolling furnace. the temperature will be very high, and the surface will be black when it is naturally cooled.

Specifications

Product name Stainless Steel Flat and Angle Bar
Place of origin China
Brand name YUHONG
Standard JIS, AISI, ASTM, GB, DIN, EN
Grade 304, 304L, 304H, 309S, 310S, 316L, etc.
Technique Hot rolled, Cold drawn
Dimension
Equal or Unequal
Thickness as your request
Length as your request
Surface Bright,black,sand Blast,polishing,pickling,etc
Application Electric Tower, Bridge Manufacturing, Chemical Engineering, Railway Construction, Building Structure, Workshop Building, etc.

A276 Stainless Steel 304 Chemical Compositions

Grade C

Mn

 Si P S Cr Ni N
SS 304 0.08 max 2 max 0.75 max 0.045 max 0.030 max 18 – 20 8 – 11 -
SS 304L 0.035 max 2.0 max 1.0 max 0.045 max 0.03 max 18 – 20 8 – 13 -
SS 304H 0.10 max 2.0 max 0.75 max 0.045 max 0.03 max 18 – 20 8 – 10.5 -

A276 Stainless Steel 304 Mechanical Properties

Grade Tensile Strength ksi (min) Yield Strength 0.2% ksi (min) Elongation % Hardness (Brinell) MAX Hardness (Rockwell B) MAX
304 75 30 40 201 92
304L 70 25 40 201 92
304H 75 30 40 201 92

A276 Stainless Steel 304 Physical Properties

SS 304/304L
Density lbm/in3 Thermal Conductivity (BTU/h ft. °F) Electrical Resistivity (in x 10-6) Modulus of Elasticity (psi x 106 Coefficient of Thermal Expansion (in/in)/°F x 10-6 Specific Heat BTU/lbm -°F Melting Range(°F)
at 68°F: 0.285 9.4 at 212°F 28.3 at 68°F 28 9.4 at 32 – 212°F 0.1200 at 68°F to 212°F 2500 to 2590
12.4 at 932 °F 39.4 at 752°F 10.2 at 32 – 1000°F
49.6 at 1652 °F 10.4 at 32 – 1500°F
SS 304H
Density lbm/in3 Thermal Conductivity (BTU/h ft. °F) Electrical Resistivity (in x 10-6) Modulus of Elasticity (psi x 106 Coefficient of Thermal Expansion (in/in)/°F x 10-6 Specific Heat BTU/lbm -°F Melting Range(°F)
at 68 °F at 68 – 212°F at 68 – 1600°F at 212°F at 932°F at 32 – 212°F in tension (E)
0.285 9.2 11 9.4 12.4 0.12 29 x 106

Applications

1. Electric Tower

2. Bridge Manufacturing

3. Chemical Engineering

4. Railway Construction

5. Building Structure

6. Workshop Building

ASTM A276 Stainless Steel 304 Angle Bar 6m Length 50*50*3mm For Industrial Furnace
