ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
Specifications
Brand Name :
YUHONG HOLDING GROUP
Model Number :
A815 S32750 S32760
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
1PC
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000T per month
Delivery Time :
10-15 DAYS
Packaging Details :
Wooden Box package
Product Name :
Duplex Steel Elbow
Type :
Seamless /Welded
Radius :
Long / Short
Application :
Gas And Oil Pipes,air,Steam,Petroleum Gas Water
Package :
Gas And Wooden Box Package
Description

ASTM A815 WP-S UNS S32750 S32760 ELBOW 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,air,Steam,Petroleum Gas Water

ASTM A815M UNS S32750 B16.9 PIPE FITTING ELBOW

Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Outside Diameter: Seamless Elbow ( 1/2″~24″), ERW / Welded / Fabricated Elbow (1/2″~48″)
Product's Angle: 5° - 180° Elbows, 90° and 45° Long Radius Elbows, Long Radius Returns, Short Radius Elbows and Returns
Wall Thickness: 3mm - 40mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Bending Radius: R=1D - 10D, 15D, 20D
Value Added Services: Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering
Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel

Manufacturing Standards of Buttweld S32750 Steel Elbow
ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43
DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN: EN10253-1, EN10253-2
ASTM A403 - ASME SA403 Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASME B16.9 Factory-Made Wrought Fittings Buttwelding
ASME B16.25 Buttwelding Ends
ASME B16.28 Wrought Steel Short Radius Elbows and Buttwelding Returns
MSS SP-43 Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Buttweld Pipe Fitting Elbow Material Grades
Stainless Steel ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel ASTM A420 WPL3, A420 WPL6
Alloy Steel ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Duplex Steel ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462
Nickel Alloy ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 )

ASTM A815 WP-S UNS S32750 S32760 Elbow 90DEG LR 2'' SCH10S B16.9 Gas And Oil Pipes,Air,Steam,Petroleum Gas Water
