316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
Specifications
Brand Name :
YUHONG
Model Number :
Stainless Steel 316L UNS S31603 Butt Weld Pipe Fittings
Certification :
API , ABS, DNV, GL , LR, NK.
Place of Origin :
CHINA
MOQ :
1
Price :
NEGOTIABLE
Payment Terms :
L/C, T/T
Delivery Time :
20-80
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ANSI,ASME
Shape :
Elbow
Connection :
Female
Technics :
Forged
Type :
Elbow
Size :
Customized Size
Application :
gas and oil pipes
Color :
Gray
Description

Stainless Steel 316L UNS S31603 Butt Weld Pipe Fittings

We are one of the biggest projects pipeline products supplier in China. Our products contain steel pipe/tube,fittings, flanges. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.

Specification:

Specifications : ASTM A403 / ASME SA 403

Standards : ASTM, ASME

Size : 1/2″ to 24″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Variants : 316L

Type : Seamless / Welded

Two Joint / Two Halve 316L Butt weld Fittings Size : 6″ to 48″

Dimensions : ANSI/ASME B16.9, B16.28, MSS-SP-43.

ASME SA403 WP316L Stainless Steel Pipe Fittings Equivalent Grade

STANDARD UNS WERKSTOFF NR. JIS GOST BS AFNOR EN
SS 316L S31603 1.4404 / 1.4435 SUS 316L 03Ch17N14M3 / 03Ch17N14M2 316S11 / 316S13 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3

ASME SA403 WP316L Stainless Steel Pipe Fittings Chemical Composition

Grade C Ni Mn S Cr Si P Mo N
SS 316L min. – 10 – – 16 – – 2 –
max. 0.08 14 2 0.03 18 0.75 0.045 3 0.1

ASME SA403 WP316L Stainless Steel Pipe Fittings Physical Properties

Grade Density (kg/m3) Specific Heat 0-1000C (J/kg.K) Mean Coefficient of Thermal Expansion (m/m/0C) Elastic Modulus (GPa) Thermal Conductivity (W/m.K) Electrical Resistivity (n.m)
0-100°C 0-315°C 0-538°C at 100°C at 500°C
316L 8000 500 15.9 16.2 17.5 193 16.3 21.5 740

ASME SA403 WP316L Stainless Steel Pipe Fittings Mechanical Properties

Grade Yield Strength 0.2% Proof (MPa) min Tensile Strength (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
SS 316L 170 485 40% 95 217

ASME SA403 WP316L Stainless Steel Pipe Fittings Application Industries

  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry

ASME SA403 WP316L Stainless Steel Pipe Fittings Test Certificates

  • EN 10204/3.1B,
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • Third Party Inspection Report, etc

Material Testing:

  • Mechanical Testing Such as Tensile of Area
  • Hardness Test
  • Chemical Analysis – Spectro Analysis
  • Positive Material Identification – PMI Testing
  • Flattening Test
  • Micro and MacroTest
  • Pitting Resistance Test
  • Flaring Test
  • Intergranular Corrosion (IGC) Test

316/316L Stainless Steel UNS S31603 Butt Weld Elbow
