A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
Specifications
Brand Name :
YUHONG HOLDING GROUP
Model Number :
YUHONG ,YHSS,YH
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA, JAPAN, THAILAND, UK, USA
MOQ :
1 PC
Price :
NEGOTIABLE
Payment Terms :
L/C, T/T
Supply Ability :
ACCORDING TO CUSTOMER'S REQUEST
Delivery Time :
10-15 DAYS
Packaging Details :
PLY-WOODEN CASE OR PALLET
Standard :
A179,A192,A210,A178
Material :
GR.A , GR.C , A1, ...
Fin type :
Wound Type,Extruded Type,Welding Type,Special Type
Package :
Iron Case
Application :
Heat Exchanger,Bolier,Air Cooler
Description

A179 A192 A210 Fin Tube Wound Type / Extruded Fin tube Boiler Finned Tube Embedded Fin Tube Heat Transfer



Fin tubes are a type of heat exchanger used in many industries. They are made of aluminum cladded carbon steel and have brazed aluminum fins. The fins increase the surface area of the tubes, which allows them to transfer heat more efficiently. This makes them ideal for applications where high heat transfer rates are required.

For Aluminum L-Foot finned tubes, the fin material is aluminum, either 1100-0. The tube material is generally carbon steel, stainless steel, or brass; however the tube can be of any material.

For Welded Helical Solid and Welded Helical Serrated finned tubes, the fin and tube materials can be any combination that can be welded together using HIGH FREQUENCY WELDING process.

The materials chosen for a given application are a function of service temperature, corrosive environment, and/or erosive environment. Common tube materials used for our welded product lines include: carbon steel, carbon moly, chrome moly, stainless steel, Inconel, and Incoloy. Common fin materials include: carbon steel; stainless steels of types 304, 310, 316, 321, 409, and 410; Nickel 200, and Inconel.

  • Base tube: Carbon steel, Stainless steel, Copper, Cupro Nickel, Aluminium, Alloy Steel
  • Fin: Carbon steel, Stainless steel, Copper, Aluminium
  • Rings: Carbon steel, Aluminium, Hot dip galvanizing

TypeDescriptionBase tubeFin specification (mm)
O.D. (mm)Fin pitchFin heightFin thick
EmbeddedG-type fin tueb16-632.1-5<17~0.4
ExtrudedSingle metal combined metal8-511.6-10<170.2-0.4
Low fin tube t-type fin tube10-380.6-2<1.6~0.3
Bamboo tube corrugated tube16-518-30<2.5/
Woundl/kl/ll type fin tube16-632.1-5<17~0.4
StringString fin tube25-382.1-3.5<200.2-0.5
U-typeU-type tube16-38///
WeldingHF-welding fin tube16-2193-255-300.8-3
H/HH type fin tube25-638-30<2001.5-3.5
Studed fin tube25-2198-305-35φ5-20

Applications :

A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Mining Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Transport Industries- Rail and Road
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Construction Industries / Building Systems
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Manufacturing Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Agriculture Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Energy Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Water Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Automotive Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Ship Building Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Nuclear Power Plant
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Paper & Pulp Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Sugar Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Engineering Cement Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Petro-Chemical Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Food Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Oil & Gas Industries
A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool Chemical & Pharmaceutical Industries


A178 A179 A192 A210 Finned Tube Wound Type / Extruded Fin tube Boiler Embedded Fin Tube Heat Transfer Air Cool
