Specifications
Brand Name :
YUHONG
Model Number :
Copper Nickel Pipes and Tubes ASTM B111 C71500 C70600,ASTM B288, ASTM B688.
Certification :
ABS, BV, ISO, ASTM, SGS
Place of Origin :
CHINA
MOQ :
100KGS
Payment Terms :
L/C, T/T
Delivery Time :
7DAYS
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle
GRADE :
UNS No. C10100, C10200, C10300, C10800, C12000, C12200, C14200, C19200, C23000, C28000, C44300, C44400, C44500, C60800, C61300, C61400, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, And C72200
STANDARD :
ASTM B111, ASTM B88 , ASTM 288 , ASTM B688
TYPE :
Straight Tube, Coil Tube , U Bend Tube,Fin Tube
PACKAGE :
BUNDLE,PLYWOOD CASE
Description

Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688

ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock

Copper or Copper Alloy UNS No. Description
C10100 Oxygen-free electronic
C10200 Oxygen-free without residual deoxidants
C10300 Oxygen-free, extra low phosphorus
C10800 Oxygen-free, low phosphorus
C12000 Phosphorized, low residual phosphorus
C12200 Phosphorized, high residual phosphorus
C14200 Phosphorized, arsenical
C19200 Phosphorized, 1 % iron
C23000 Red Brass
C28000 Muntz Metal
C44300 Admiralty Metals, B, C, and D
C44400
C44500
C60800 Aluminum Bronze
C61300
C61400 Aluminum Bronze, D
C68700 Aluminum Brass, B
C70400 95-5 Copper-Nickel
C70600 90-10 Copper-Nickel
C70620 90-10 Copper-Nickel—Welding Grade
C71000 80-20 Copper-Nickel
C71500 70-30 Copper-Nickel
C71520 70-30 Copper-Nickel—Welding Grade
C71640 Copper-nickel-iron-manganese
C72200


Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688

TESTING: ET; HT; Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing.

Cupro Nickel Rods 90/10 and 95/5

Cupro Nickel Rods For 90/10

Chemical Properties
Pb 0.05 Max.
Fe 1.00 - 1.80
Mn 1.00 Max.
Zn 1.00 Max.

Cu + Ag Remainder Ni + Co 9.00 - 11.00

Mechenical Properties
Light Drawn
Flattening Test Reqd. (After 'O')
U.T.S. ksi 45.00 Min
Y.S. at 0.5% Ext. ksi 35.00 Min.

Expansion Test 30% at 60 degree Reqd. (After 'O')

Annealed Temper
Flattening Test Reqd.
Grain Size at 75 X mm Avg. 0.010 - 0.045
U.T.S. ksi 40.00 Min.
Y.S. at 0.5% Ext. ksi 15.00 Min.

Expansion Test 30% at 60 degree Reqd.

Cupro Nickel Rods For 95/5

Chemical Properties
Sn 0.10 Max.
Pb 0.05 Max
Ni 4.00 - 5.00
Fe 0.10 Max.
Mn 0.25 Max.
As 0.10 Max.
Cu + Ag 95.00 - 96.000
Sb 0.01 Max.
Bi 0.0025 Max.

Oxygen (O2) 0.08 Max.

Mechenical Properties
Annealed
U.T.S. MPa 216 - 275 (Strip cut from Ring Tube)
%Elongation at 5.65Sq.Rt So G.L. 40.00 Min. (Strip cut from Ring Tube)
Flattening Test Reqd.
Bend Test Reqd. (180 degree close)


Cupro Nickel Pancake Coils
Copper-nickel brake tubing provides superior reliability and assures both manufacturers and vehicle owners improved durability for effective long-life functioning of the brake system.Coils Available in 5 mtr, 10 mtr & 15mtrs.

Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688
