Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
Specifications
Brand Name :
YUHONG
Model Number :
TP316L,TP304,TP304L,SUS316L,SUS304
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
100KGS
Payment Terms :
L/C, T/T
Delivery Time :
7DAYS
Packaging Details :
PLYWOOD CASE,BUNDLE,PALLET
OD :
0.1MM TO 25MM
TYPE :
SEAMLESS,WELDED
SHAPE :
ROUND ，SQUARE AND OTHER SPECIAL SECTION
SURFACE :
Annealing,pickling,Bright
USAGE :
MEDICAL,CHEMICAL,WATCH,ANTENNA...
PACKAGE :
PLYWOOD CASE,PALLET
Description

Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​

The Stainless Steel Capillary Tubes are used while supplying liquids and gases from sensors to measuring instruments. The tubes are used in various critical applications with having inner surface free from oil, grease and dust particles. These tubes are available in different sizes, tolerances and thickness as per the requirements of our clients.

Features
  • Tight tolerances
  • Free from oil & dust particles from inside
  • Rust resistant
Applications
  • Gas and liquid lines
  • Medical instruments (hypodermic needle)
  • Chromatography
  • Measurement in remote thermometer systems (with or without compensation)

Available Grades : 304, 304L, 316, 316L

Available Types : Seamless & Welded

Available Size : OD :Min. 0.5mm to 6mm

WT:0.02 to 2mm

Length Max.: 1000m /pc

** All Round Tubes are Quoted OD x Wall.

ID Listed in Center Area
Wall Thickness (mm)
O.D. (mm) 0.075 0.08 0.1 0.125 0.15 0.175 0.2 0.225 0.25 0.3 0.35 0.375 0.4 0.45 0.5 0.6 0.75 0.8 0.85 1 1.25 1.5 1.8 2 2.5
0.1
0.2 0.04
0.3 0.15 0.14 0.1
0.4 0.2
0.5 0.3 0.2
0.55
0.6 0.4
0.62 0.32
0.7 0.45 0.4
0.8 0.5 0.45 0.3 0.1
0.9 0.5
1 0.8 0.7 0.6 0.5 0.4 0.3
1.1 0.7
1.2 0.8 0.3
1.3 0.85 0.8
1.4 1
1.5 1.2 1.1 1 0.8 0.7 0.5
1.6 1.2 1 0.6 0.1
1.7 1.3
1.8 1.3 1
1.9 1.4
2 1.8 1.6 1.5 1.4 1
2.2 1.6 0.5
2.4 1.6
2.5 2.1 2 1.9 1.7 1.5
2.6 2
2.8 2
3 2.6 2.5 2 1.5 1
3.2 2.8 2.4
3.25 0.75
3.5 2.75 2.5 2.3
4 3.5 3 2.5 2 1.5 1
4.5 4 3.5
5 4.7 4.6 4.5 4 3.5 3 2 1.4
5.3 4.8
5.5 3.5
6 5.7 5.5 5.2 5 4.5 4.4 4 3 2.4 2 1

Precision Capillary Tube, Bright Annealed, Stainless Steel Seamless Tube,TP304/TP316L​
