ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
Specifications
Brand Name :
YUHONG
Model Number :
A815 WP-S UNS S32750
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
1Piece
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According to Client's Requirements
Delivery Time :
5-90 Days
Packaging Details :
According to Client's Requirements/ Ply-wooden Case/ Pallet
Specifications :
ASTM A815 / ASME SA815
Grade :
WP-S UNS S32750
Type :
Seamless, Welded
Size :
1/8'' to 100''
Product Name :
stainless steel pipe fittings
Applications :
Construction,gas and oil pipes,Petroleum gas water
Description

ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9

ASTM A815 WP-S UNS S32750 Super Duplex Stainless Steel Pipe Elbows are one of the buttweld fittings and are available in various shapes, sizes and specifications. They are used in marine industries, nuclear projects, power plants and other chemical industries. The durability of ASTM A815 WPS32750-S Fittings is excellent and its specification has two types i.e. WP and CR. By using several chemicals like carbon, manganese, phosphorus, silicon and many more are used. Several grades are also involved like ASTM A815 UNS S31803, A815 UNS S32750 and more. ASTM A815 WPS32750-S Elbow is usually designed to work in high strength and corrosion resistance. All these features will be available in the product manufactured by our Group.

Specification

Types Seamless / ERW / Welded / Fabricated
Thread NPT, BSPT, BSPP
Elbow Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D.
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799

Equivalent Grades:

STANDARD WERKSTOFF NR. UNS
Super Duplex SS 2507 1.4410 S32750 / S32760

Seamless/ Welded 100% Radiography Tested

A815 Super Duplex Steel Pipe Fittings Types Size
Elbow – Long Radius Elbow – Short Radius Sizes 1/8" – 48"
Cross Reducing Cross
Full Coupling Half Coupling
Concentric Reducer Eccentric Reducer
Equal Tee Reducing Tee

Chemical Composition:

Grade C Mn Si P S Cr Mo Ni N Fe
S32750 0.03 max 1.2 max 0.8 max 0.035 max 0.02 max 24 – 26 3 – 5 6 – 8 0.24 – 0.32 58.095 min
S32760 0.05 max 1 max 1 max 0.03 max 0.01 max 24 – 26 3 – 4 6 – 8 0.20 – 0.3 57.61 min

Mechanical properties:

Grades Density (g/cm 3) Density (lb/in 3) Melting Point (°C) Melting Point (°F)
S32750 / S32760 7.8 0.281 1350 2460

ASTM A815 WP-S UNS S32750 Seamless Super Duplex Stainless Steel 90° Elbow LR B16.9
