ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
Specifications
Brand Name :
YUHONG
Model Number :
ASTM, JIS, DIN, EN
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
100KGS
Price :
NEGOTIABLE
Payment Terms :
L/C, T/T
Supply Ability :
ACCORDING TO CUSTOMER'S REQUEST
Delivery Time :
7 DAYS
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Name :
Nipple
Standard :
ASTM A182
Material :
F304
Usage :
Joining Pipe Lines
Description

ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings

ASME B16.11 304 Forged Couplings are mostly used various indutsrial aaplications like in chemical industries, ship buildings, fats and fertiliser industries. It is reliable and has high tolerance capacity. UNS S30400 Forged Elbows that make 45° or 90° changes of direction in the run of the pipe and accessible to our valuable customers in different range of diameters, wall thicknesses and sizes at best price. Also We offer wide range of Stainless Steel ASTM A182 304 Forged Fittings such as ASME B16.11 304 Forged Elbow, A182 SS 304 Equal Tee, SS 304 Coupling, UNS S30403 Threaded Pipe Cap, DIN 1.4307 Threaded Union, SS 304 Bushing, SS 304 Plug, SS 304 Pipe Nipple, SS 304 Street Elbow.
Equivalent Grades of ASME SA182 F304/F304L Forged Steel Threaded Fittings
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 304 1.4301 S30400 SUS 304 304S31 08Х18Н10 Z7CN18‐09 X5CrNi18-10
SS 304L 1.4306 / 1.4307 S30403 SUS 304L 3304S11 03Х18Н11 Z3CN18‐10 X2CrNi18-9 / X2CrNi19-11
SS 304H 1.4301 S30409 – – – – –

Specification of Werkstoff No 1.4301 Stainless Steel Forged Threaded Pipe Fittings

Specifications ASTM A182 & ASME SA182
Stainless Steel Forged Pipe Fittings size 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
ASTM A182 F304/F304L Fittings Dimensions ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Werkstoff No 1.4301 SS 304 Thread Fittings NPT , BSPT, BSPP
ASME SA182M F304L FittingsType DN15-DN1200
End Threaded, Welding, JIC
Pressure Rating 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Connection Welding
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings
UNS S30400 Forged Steel Fitting Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Industrial Applications for ASME SA182M SS 304 Pipe Fittings
  • Bitumen upgraders.
  • Heavy oil refineries.
  • Nuclear power (mostly seamless).
  • Petrochemicals and acids.
Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

SS 304 Forged Pipe Fittings Manufacturing Standard

BS3799 Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
MSS SP-43 Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
MSS SP-95 Swage(d) Nipples and Bull Plugs
ASTM A182 – ASME SA182 Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASME B16.11 Socket Welding and Threaded Forged Fittings

Stainless Steel ASME SA182 F304L Forged Threaded Pipe Fittings Chemical Composition
Grade Mn Si Cr N P C S Ni Ti
SS 304 2.0 max 1.0 max 17.00 – 19.00 0.10 max 0.045 max 0.08 max 0.030 max 9.00 – 12.00 5(C+N) – 0.70 max
SS 304L 2.0 max 1.0 max 17.00 – 19.00 0.10 max 0.045 max 0.04 – 0.10 0.030 max 9.00 – 12.00 4(C+N) – 0.70 max
ASTM A182 SS 304 Forged Steel Fittings Mechanical Properties

Grades
Tensile Strength		 Yield Strength (0.2%Offset) Melting Point
Density		 Elongation
SS 304 Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 1400 °C (2550 °F) 8.0 g/cm3 35 %
SS 304L Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 1400 °C (2550 °F) 8.0 g/cm3 35 %
SS 304H Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 1400 °C (2550 °F) 8.0 g/cm3 40 %

ASTM A182 F304 Nipple MSS SP-79 Stainless Steel Forged Fittings
