ASTM A249 / ASME SA249 TP316L STAINLESS STEEL WELDED TUBE ET AVAILABLE
ASTM A249 / ASME SA249 TP316L STAINLESS STEEL WELDED TUBE ET AVAILABLE
ASTM A249 / ASME SA249 TP316L STAINLESS STEEL WELDED TUBE ET AVAILABLE
ASTM A249 / ASME SA249 TP316L STAINLESS STEEL WELDED TUBE ET AVAILABLE
ASTM A249 / ASME SA249 TP316L STAINLESS STEEL WELDED TUBE ET AVAILABLE
ASTM A249 / ASME SA249 TP316L STAINLESS STEEL WELDED TUBE ET AVAILABLE
Specifications
Brand Name :
YUHONG
Model Number :
TP316, TP316L
Certification :
ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
100 KGS
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100Ton/Month
Delivery Time :
7 days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Surface :
Bright Annealed (BA), Pickled And Annlealed , Polished
TPI :
BV, SGS, LR, ABS, DNV, GL , MOODY, IBR, APS, V-TRUST,CCIC
NDT :
ET, HT, PT
Description

Stainless Steel Welded Tube ASTM A249 and ASME SA249 TP316L For Heat Exchanger

YUHONG Group deal with Stainless steel pipe and tube already more than three decades, every year sell more than 80000 tons of stainless steel seamless pipe and tube. Our client already cover more than 45 countries.

ASME SA249 TP 316L Tubing Mechanical Properties

Tensile Stress (Mpa) Yield Stress (Mpa) Elongation (%) Elongation (%)
SA 249 316L 485 170 35 25
1.4404 490-690 190 40 30

SA249 316L SS Tube Chemical Composition

SA 249 C Mn P S Si Ni Cr Mo N
316L 0.035 2.00 0.045 0.030 1.0 10-14 16-18 2-3
1.4404 0.03 2.00 0.040 0.015 1.0 10-13 16.5-18.5 2-2.5 0.11

SS SA249 UNS S31603 Equivalent

1. JIS SUS316L

2. WNR. / DIN 1.4404

3. UNS S 31603

4. AISI 316L

5. EN 02Cr17Ni12Mo2

6. China GB 022Cr17Ni12Mo2

Standard Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger and Condenser Tubes oF A249 / SA249
1.1 This specification covers nominal-wall-thickness welded tubes made from the austenitic steels listed in Table 1, with various grades intended for such use as boiler, superheater, heat exchanger, or condenser tubes.


1.2 Grades TP304H, TP309H, TP309HCb, TP310H, TO310HCb, TP316H, TP321H, TP347H, and TP348H are modifications of Grades TP304, TP309S, TP309Cb, TP310S, TP310Cb, TP316, TP321, TP347, and TP348, and are intended for high-temperature service such as for superheaters and reheaters.

1.3 The tubing sizes and thicknesses usually furnished to this specification are 1/8 in. [3.2 mm] in inside diameter to 5 in. [127 mm] in outside diameter and 0.015 to 0.320 in. [0.4 to 8.1 mm], inclusive, in wall thickness. Tubing having other dimensions may be furnished, provided such tubes comply with all other requirements of this specification.

1.4 Mechanical property requirements do not apply to tubing smaller than 1/8 in. [3.2 mm] in inside diameter or 0.015 in. [0.4 mm] in thickness.

1.5 Optional supplementary requirements are provided and, when one or more of these are desired, each shall be so stated in the order.

1.6 The values stated in either inch-pound units or SI units are to be regarded separately as standard. (A combination of values from the two systems may result in nonconformance with the specification.) The inch-pound units shall apply unless the "M" designation of this specification is specified in the order.

Other Material Chemical Compositions
Grade UNS Composition, %
Design C Mn P S Si Cr Ni Mb Ti Nb N Cu Ce B Al
TP304 S30400 0.08 2 0.045 0.03 1 18.0–20 8.0–11 . . . . . . . . . . . . . . . . . .
TP304L S30403 0.035 2 0.045 0.03 1 18.0–20 8.0–13 . . . . . . . . . . . . . . . . . .
TP304H S30409 0.04 – 0.1 2 0.045 0.03 1 18.0–20 8.0–11 . . . . . . . . . . . . . . . . . .
TP310S S31008 0.08 2 0.045 0.03 1 24.0- 26 19.0- 22 0.8 . . . . . . . . . . . . . . .
TP310H S31009 0.04 – 0.1 2 0.045 0.03 1 24.0–26 19.0–22 . . . . . . . . . . . . . . .
TP310H S31035 0.04 – 0.1 0.6 0.025 0.015 0.4 21.5–23.5 23.5–26.5 . . . . . . 0.40- 0.6 0.20- 0.3 2.5- 3.5 . . . 0.002- 0.008
TP316 S31600 0.08 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .
TP316L S31603 0.035 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .
TP316H S31609 0.04 – 0.1 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .
TP317 S31700 0.08 2 0.045 0.03 1 18.0–20 11.0–15 3.0–4 . . . . . . . . . . . . . . .
TP317L S31703 0.035 2 0.045 0.03 1 18.0–20 11.0–15 3.0–4 . . . . . . . . . . . . . . .
TP321 S32100 0.08 2 0.045 0.03 1 17.0–19 9.0–12 . . . Ti 5 × (C+N) min, 0.70 max . . . 0.1 . . . . . .
TP321H S32109 0.04 – 0.1 2 0.045 0.03 1 17.0–19 9.0–12 . . . 4(C+N) min; 0.70 max . . . 0.1 . . . . . .
TP321H S32654 0.02 2.0-4 0.03 0.005 0.5 24.0–25 21.0–23 7.0-8 . . . . . . 0.45- 0.55 0.30-0.6 . . .
TP321H S33228 0.04 – 0.08 1 0.02 0.015 0.3 26.0–28 31.0–33 . . . . . . 0.60- 1 . . . . . . 0.05 – 0.1 0.025
TP321H S34565 0.03 5.0-7 0.03 0.01 1 23.0–25 16.0–18 4.0-5 . . . 0.1 0.40- 0.6 . . . . . .
TP347 S34700 0.08 2 0.045 0.03 1 17.0–19 9.0–13 . . . . . . See Spec . . . . . . . . .
TP347H S34709 0.04 – 0.1 2 0.045 0.03 1 17.0–19 9.0–13 . . . . . . See Spec . . . . . . . . .
Alloy 20 N08020 0.07 2 0.045 0.035 1 19.0–21 32.0–38 2.0–3 . . . See Spec . . . 3.0– 4 . . . . . . . . .
Alloy 20 N08367 0.03 2 0.04 0.03 1 20.0–22 23.5–25.5 6.0–7 . . . . . . 0.18–0.25 0.75 . . . . . . . . .
Alloy 20 N08028 0.03 2.5 0.03 0.03 1 26.0–28 30.0–34 3.0–4 0.60–1.4
Alloy 20 N08029 0.02 2 0.025 0.015 0.6 26.0–28 30.0–34 4.0–5 0.6– 1.4

Uses and Applications

1. Common industrial services (Petroleum, chemical, paper, fertilizer, fabric, aviation and nuclear)
2. Fluid, gas and oil industry
3. Heat transmission and pressure service
4. Construction and ornamental
5. Boilers and Heat exchangers
6. Decoration purpose, boiler, auto parts, medical device, food industry, building materials)
