ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
ASTM A179/ASME SA179 Heat Exchanger Tube Cold Drawn Killed with 100% ET/HT
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A179/ASME SA178
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
China
MOQ :
1000KGS
Price :
USD 700-1000 /TONS
Payment Terms :
L/C, T/T
Supply Ability :
ACCORDING TO CUSTOMER'S REQUEST
Delivery Time :
20-70DAYS
Packaging Details :
Ply- Wooden Case/Plastic Bag / Plastic Cap
OD :
6- 168 mm
WT :
1-15 mm
Length :
33000 mm Max
Description

Product Description

YUHONG ASTM A179 Seamless Heat Exchanger Tube Cold Drawn, with 100% ET/HT

Standard
ASTM A179,
Material
Carbon Steel
Size
WT: 1-15mm; OD: 6-168mm; Length: max 33000mm
Applications
For Heat-Exchangers,
Cold Condensers and High-Pressure Services,
High-Temperature Services for H Constructions
Manufacture
Tubes are manufactured by seamless process and both hot finished and cold finished are applicable.
Heat treatment
Hot finished tubes need not be heat treated.
Cold Finished tubes are heat treated after the final cold finishing pass at a temperature of 1200℉(650℃) or higher
Test
Tension Test, Flaring Test, Flange Test,
Reverse Test, Hardness Test,
Hydrostatic or Nondestructive Electric Test etc

Chemical Composition

C
Mn
P
S
Si
0.06-0.18
0.27-0.63
≤0.035
≤0.035
≤0.25

Mechanical Properties

Tensile Streghth, min
ksi [Mpa]
Yield Point, min
ksi [Mpa]
Elongation, %
47[325]
26[180]
≥35%

Hardness

Brinell Hardness
Rockwell Hardness Number
WT≥0.200in(5.1mm)
WT<0.200in(5.1mm)
137HRB
77HRB

Tolerance for OD and WT(SA-450/SA-450M)

OD in(mm)
+
-
WT in(mm)
+
-
<1''(25.4)
0.10
0.10
≤1.1/2''(38.1)
20%
0
1''~1.1''(25.4~38.1)
0.15
0.15
>1.1/2''(38.2)
22%
0
>1.1/2''~<2''(38.1~50.8
0.20
0.20
2''~<2.1/2''(50.8~63.5)
0.25
0.25
2.1/2''~<3''(63.5~76.2)
0.30
0.30
3''~<4''(76.2~101.6)
0.38
0.38
4''~<7.1/2''(101.6~190.5)
0.38
0.64
>7.1/2~9''(190.5~228.6)
0.38
1.14

Product Details
