Easy Operation Roofing Sheet Roll Forming Machine , Standing Seam Machine
Easy Operation Roofing Sheet Roll Forming Machine , Standing Seam Machine
Specifications
Model Number :
900
Certification :
CE
MOQ :
1 SET
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
30 working days after receiving the 30 percent deposit
Packaging Details :
plastic film packaged to protect the machines , and the macines loaded into the container.
Type: :
Cold Rolling Mill
Dimension(L*W*H): :
6500*1300*1100
Weight: :
3-10tons, According to customer
oltage: :
220v-380v-440v
Final product: :
Steel Plate
Shaft material: :
45# Steel Outer Diameter: 40mm Roll material:
Roll Material: :
Forged 45# steel0mm
Warranty: :
12 MONTHS
Description

Freight Car Panel / Truck Panel Roll Forming Machine For Lorry Plate

Main Features

1) Automatic roll forming machine production line, easy in operation and maintenance.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) Can customize the models as clients' profile drawings or clear requirements.

4) We provide overseas debugging and operation after clients order our forming machines.

5) The forming machine has PLC control system, with Delta or Siemens brand, easy used and durable.

Easy Operation Roofing Sheet Roll Forming Machine , Standing Seam Machine

Model:576 Car Panel

Configurations Manual Uncoiler ,Guiding Platform ,Coil Strip Leveler ,Main Machine Of Roll Forming ,Electro-Motor,Cutting Device ,Hydraulic Station ,PLC Control, Supporter Table.
Control System PLC Delta Inverter
Main Frame 300mm H-Beam
Main Power 11 kw
Pump Power 15 kw
Power Supply 380V, 3-Phase,50Hz
Forming Speed 10m/min
Roll Station 16 stands
Roller Diameter 80mm
Hydraulic Pressure 18-20MPa
Forming Size 576 mm
Feeding Thickness 0.8-1.4mm
Feeding Width 1000mm
Backboard Thickness 20mm
Chain Size 52mm
Cutter Standard Cr12
Roller Standard Cr12
Cr-Plating Size 0.05mm
Overall S 9000×1300×1500mm
Total Weight 8t

All technical parameters can be changed,according to user s need

Easy Operation Roofing Sheet Roll Forming Machine , Standing Seam Machine

Packing And Delivery;

Packaging
Size 7500mm * 1600mm * 1600mm
Weight 6.5T

Packaging Details

 The normal package is covered with plastic film or pack it according to customers special request.
Delivery

Delivery Details

 We have many years' experience in loading the roll forming machine into the container, so we can take advantage of as much as space of the container to save the freight cost.

Easy Operation Roofing Sheet Roll Forming Machine , Standing Seam Machine

Company Information

1. Cangzhou Kingter Roll Forming Machine Co.,ltd is located in " The Town of Casting Molds", enjoys convenient transportations, Di Kou Zhang Village, Nancang Road, Botou City, Hebei Province, China.

2. We are a manufacture of roll forming machine, all of the parts we made ourselves, so, we can insure the quality of our products.

3. Cangzhou Kingter Roll Forming Machine is a company integrating production, processing, sale, trade, so we will give our customers the best price.


FAQ

1 How can we install the spiral welded pipe roll forming machine?

a When finished the spiral welded pipe roll forming machine, you can with your techinian or one of your worker to our factory inspect the machine. While we run the spiral welded pipe bending machine , we can teach your techinian how install the machine and run the machine.

b If you do not plan to come the inspect the machine running, we can send you the machine running vedios and machine manual which telling how to install the machines.

c We also have a strong machine installing team which ever go to custoer's country install many machines.

If you demand our technian to work with you, our techinian can go to your place teach our worker's .

But, our techinian's accomodations should be arranged by your sides and pay 50 USD/day .
