AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm
Specifications
Brand Name :
HNJBL
Model Number :
AH32
Certification :
ISO9001, ISO ,BV
Place of Origin :
China
MOQ :
1
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
50000 ton/month
Delivery Time :
15-25 working days
Packaging Details :
Standard packing for shipping
Application: :
Ship Plate, Boiler Plate, Container Plate, making pipes,
Processing Service: :
Welding, Punching, Cutting, Bending, Decoiling
Model Numbe :
Grade B/C/D/ AH32/AH36
Thickness Range :
5 mm -150 mm
Width Range :
1500 mm - 3900 mm
Shape :
Flat Steel Plate
Technology :
Cold Rolled.hot Rolled
Description

Shipbuilding AH32 AH36 Steel Plate / Shipbuilding AH32 AH36 Steel sheet

1 Commodity: AH32,EH36 ship plate

2 Material: CCSA~CCSD,AH32,AH40,DH32 etc
3 Standard: CCS/BV/LR/ABS
4 Thickness: 3-300mm
5 Width: 2000- 3000mm

6 MOQ: 10 TON,with negotiation

7 Port: Tianjin Shanghai Qingdao

8 Package: standard package or as your requirement

9 Delivery Time: within 15 days after receiving the deposite or as request

Product Name
Shipbuilding AH32 AH36 Steel Plate / Shipbuilding AH32 AH36 Steel sheet
Material
Carbon Steel
Standard
ABS/NKK/BV/DNVGL grade A/B/D/E/, CCS, DNV, GL, ABS, LR, BV, etc
Grade
Grade A/B/D/E/ AH32/AH36/DH32/DH36/EH32/EH36
Q345CDE/Q390CDE/Q420CDE/Q460CDE

Q550CDE/Q690CDE
Q345CDE-Z15/Z25/Z35
Shape
flat plate, Angle Bar, Unequal Angle Steel,
Size
Thickness: 6mm-650mm

Width: 1500mm-4020mm

Length: 3000mm-18800mm
Payment terms
T/T,L/C,western union, Paypal
Price terms
CFR,FOB,CIF,Ex-work,CNF
Application
Shipbuilding Steel Plate
Grade A steel plate is used for shipbuiling's hull structure and platform. The shipbuilding steel plate grade A is the common tensile strength steel. It has good toughness properties and higher strength, strong corrosion-resistance,the processing properties,and welding properties.ASTM A131 Grade A steel plate can be used in the manufacture of the ship's hull structure whose weight is below 10000 tons,and usually do navigation around coastal and river area.
Package
Standard export seaworthy package or as required.
Contact
If you have any question,please feel free to contact me.

AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm

Chemical and Mechanical Requirements

Elements

C

Mn

Al

Si

P

S

AH32

≤0.18

0.7~1.60

≥0.015

0.10~0.50

≤0.04

≤0.04

DH32

≤0.18

0.90~1.60

≥0.015

0.10~0.50

≤0.04

≤0.04

EH32

≤0.18

0.90~1.60

≥0.015

0.10~0.50

≤0.04

≤0.04

AH36

≤0.18

0.7~1.60

≥0.015

0.10~0.50

≤0.04

≤0.04

DH36

≤0.18

0.90~1.60

≥0.015

0.10~0.50

≤0.04

≤0.04

EH36

≤0.18

0.90~1.60

≥0.015

0.10~0.50

≤0.04

≤0.04

Shipbuiding Standards from Different Countries

Shipbuilding steel plates are produced under the approval of production methods of classification societies in different countries refers to offshore and marine steels.

  • ABS (American Bureau of Shipping)
  • BV (Bureau Veritas)
  • CCS (China Classification Society)
  • DNV (Det Norske Veritas)
  • GL (Germanischer Lloyd)
  • HR (Hellenic Register of Shipping)
  • KR (Korean Register of Shipping)
  • LR ​(Lloyd's Register of Shipping)
  • NK (Nippon Kaiji Kyokai)
  • RINA (Registro Italiano Navale)
  • RS (India Register of Shipping)

Mechanical Properties

​

Steel Grade

​

Thickness/mm

​

​

Yield point/ MPa

​

Tensile strength/ MPa

​

​

Elongation/ %

V-type impact test

Temperature/

℃

Average impact absorption ​

workAkv/J

Vertical

Horizontal

A

≤50

≥235

400~490

≥22

-

-

-

B

≤50

≥235

400~490

≥22

0

≥27

≥20

D

≤50

≥235

400~490

≥22

-10

≥27

≥20

E

≤50

≥235

400~490

≥22

-40

≥27

≥20

AH32

≤50

≥315

440~590

≥22

0

≥31

≥22

DH32

≤50

≥315

440~590

≥22

-20

≥31

≥22

EH32

≤50

≥315

440~590

≥22

-40

≥31

≥22

AH36

≤50

≥355

490~620

≥22

0

≥34

≥24

DH36

≤50

≥355

490~620

≥22

-20

≥34

≥24

EH36

≤50

≥355

490~620

≥22

-40

≥34

≥24

Product Advantages

AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm

PRODUCT APPLICATION

AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm

PRODCTION PROCESS

AH36 DH36 EH36 Mild Steel Plate CCSA Cold Rolled Grade B 3mm-300mm

Our team

*Reply your inquiry within 24 hours

*Customized design is available,Third Party Inspection is welcomed

*Delivery the goods to our customer all over the world with speed and precision

FAQ

1. How about your price?
Although we are brand name products,but our prices are very favorable and competitive. Customer from all over the world to purchase our products, because our best price.
2. How long is your warranty?
Our Warranty is 12 month
3. What's your payment?
Our Payment could be
(1) 100% T/T
(2) 30% in advance, others before shipment.
(3)Advance, others letter of credit.
4. What is your payment method?
L/C
D/A
D/P
T/T
Western Union
MoneyGram

5. Could you special design and produce for you?
Sure, we have all kinds of professional engineers,
Could design and produce special product according to customer requested.
Such as: special Size, special control, or OEM, etc.
6. Do you looking for Agent?
Yes, we're looking for the agent all over the world, please contact us for further discussion.
