Specifications
Brand Name :
KXD
Model Number :
S0011
Certification :
SGS, ISO, CE
Place of Origin :
Qingdao China
MOQ :
500 square meters
Price :
$50-80 per square meter
Payment Terms :
L/C,T/T
Supply Ability :
3000 tons per month
Delivery Time :
30-40 working days
Packaging Details :
steel pallet / Bulk
Painting thickness and Color :
Custom
Connection Form :
Bolt Connection
Advantage :
Lightweight
optional :
skylight panel, ventilation, Glass curtain
Design Style :
Modern
Design :
Free technical support with free drawings
Construction Type :
Dry Construction
Install :
Quick and Easy installing
Description

Prefab steel structure building Description:

Application

residential steel home/house

steel farm building, poultry, cow shed etc.

Logistics warehouse, industrial workshop

commercial building

storage shed, Hangar

sport hall, steel hall,shopping mall, office

Specification

Clear span:

(width)

6~50m without middle column

Height

2~20m

Length

as requirements

Material Grade

Q355b, Q235b, S355JR, S235JR or as request

Column/beam

Welded or Hot rolled H , I , box steel

Tie beam

round pipe or square tube or as request

X brace

round steel bar, angle steel or as request

Purlin

C /Z section steel, thickness 2.0mm,2.2mm,2.5mm,3.0mm

sag rod

steel round bar, angle, C purlin etc

Wall & Roof

steel sheet (0.4~0.75mm)
EPS, Rock wool, glass fiber ,PU insulated sandwich Panel
(Thickness:50mm,75mm,100mm,150mm,200mm)

Gate

Electric rolling shutter /Sliding door

Exit Door

Aluminum alloy door/ Glass door/ steel security door/stainless steel security door

Window

Plastic steel or Aluminum alloy frame sliding window/ swing window

Surface

Alkyd painting

rich-zinc epoxy painting
hot dipped galvanize

Certificate

ISO90001,CE EN1090 EXC2 ,IWE etc

Quality Control

The third party ,SGS, QIMA, BV all accept

Crane

5MT, 10MT, 15MT, 20MT, 30MT etc.

Other accessories

gutter, flashing trimming cover, down spout, ventilation, skylight, bolts, rivets, anchor bolt, self tapping screw, sealant etc

Package

main steel frame loads in 40'OT / packed steel pallet

roof &wall panel load in 40'HQ!
