Fabric Cloth Finishing Machines Less Consumption / Single Or Double Drive
Fabric Cloth Finishing Machines Less Consumption / Single Or Double Drive
Fabric Cloth Finishing Machines Less Consumption / Single Or Double Drive
Fabric Cloth Finishing Machines Less Consumption / Single Or Double Drive
Specifications
Brand Name :
VIROCK
Model Number :
VK-NM
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 SET
Price :
NEGOTIABLE
Payment Terms :
L/C, D/A, T/T
Supply Ability :
4 sets per month
Delivery Time :
in 90 days
Packaging Details :
Wooden case
Machine drive side :
R/L
Main drive mode :
Single/double drive
Chamber quantity :
Custom-made
Chamber door thickness :
150mm
Chamber floor thickness :
80mm
Heating media :
Optional
Door open way :
Auto/manual
Fabric carry by :
Pin/clip/pin&clip
Description

High automation Textile Finishing Machine , Humanization design , Less consumption

1. Main technical data:

Fabric width 1200mm-3600mm
Roller width 1400mm-3800mm
Chamber door thickness 150mm
Padder type Slant /vertical padder
Main drive Single drive (22Kw)/Double drive (11Kw x 2)
Chamber quantity As customer required
Guide roller diameter 125mm / 150mm
Heating media Thermal oil/Natural gas/Steam/Electricity or any two combined
Entry rail type Horizontal rail
Entry rail length 3m/6m
Exhaust fan No. Optional

2. Machine feature:

1) Padder mangle:

The stenter machine is usually equipped with a heavy-duty two /three-bowl padder mangle designed to impregnate starch or finish chemicals or tint agents and squeeze all types of fabrics, including delicate textile fabrics made from natural fibres, man-made fibres and other blended fabrics. Generally both of the driving rollers & the driven rollers are usually made from heavy duty pipes with heavy shaft and covered with NBR. The chemical troughs are made of stainless steel with guide rollers suspended from the side walls. Trough can be easily lifted or lowered for easy cleaning. Chemical dosing arrangement can also be provided.

2) Electric unit:

Imported Programmable logic range control (PLC):

● All fabric transport drives with frequency-controlled AC-drives.

● Control and monitoring instruments in the inlet and outlet area.

● Set-up automation for the operating parameters: production speed, fabric feeding, fabric overfeeding, stretching device, selvedge tensioning and air circulation, exhaust etc.
