Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement
Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement
Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement
Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement
Specifications
Brand Name :
JIUQI
Model Number :
35BYZ-20
Certification :
RoHS,ISO9001
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
100PCS
Price :
$7~$15/PCS
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
200000 PCS/MONTH
Delivery Time :
Trial orders :2 WEEKS Bulk orders: within 3 weeks
Packaging Details :
with export carton . Bulk order with pallets
STEP ANGLE(DEGREE) :
7.5
VOLTAGE :
12V
RESISTANCE :
35±10%
MAX TRAVEL :
20MM
PHASE :
2
TYPE :
PERMANENT MAGNET
HIGH LIGHT :
Electric Linear Actuator Motor,High torque stepper motor,Threaded shaft linear stepping motor
PRODUCT NAME :
35MM LINEAR MOTOR
Description

High Precision Hybrid Motor Stepping Motor For Precise Position Movement

1. Description:

  • Linear stepper motor mainly used in valve control, medical equipment, automatic buttons, , printers, robots , textile machines and other related fields.
  • customizable front plate available
  • Thrust can be customized
  • Wiring part can be pin , connecting wires, FPC ,FFC, PCB, etc.


2. Specification

PNStep angleVoltagePhaseCurrentResistanceInductancePush forceStart frequencyRotate frequencyPush distanceStep length
(°)VDC　mAΩmHg(200pps)ppsppsmmmm
35BYZ-2015122≤2505343≥5≥500≥600200.0417
15122≤3503022≥5≥500≥600200.0417
15122≤1508565≥5≥500≥600200.0417
1552≤3002216≥5≥500≥600200.0417
7.5124≤2505343≥5≥500≥600200.02085
7.5124≤3503022≥5≥500≥600200.02085
7.5124≤1508565≥5≥500≥600200.02085
7.554≤3002216≥5≥500≥600200.02085


3. Mechanical Dimension:MM

Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement

4. Typical Applications


· Medical Equipment
· Automatic Control
· 3D Printer
· Precision Calibration
· Precise Position Movement

5. Terms of trade

Terms of priceFOB,CIF,CFR,EXW,DDP,etc.
Terms of payment100% T/T in advance for samples
Bulk quantity payment way can be negotited
Warranty12 months limited warranty once the items are delivered to the buyer.
Lead timeUsually within 2 weeks for trial orders, within 3 weeks for bulk orders.
PackageCartons /Pallets
Place of loadingShanghai, Ningbo, etc.
Delivery timeUsually within 5 working days by Express 15-30 working days by vessel


6. ​Shipping

Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement
7.Payment

Nema 8 Nema 17 Nema 11 Geared Stepper Motor Nema 23 Hybrid For Precise Position Movement
