Automatic Two Side Bottle Labeling Machine Adhesive Label Sticker Shampoo Wine
Automatic Two Side Bottle Labeling Machine Adhesive Label Sticker Shampoo Wine
Specifications
Brand Name :
Boson
Model Number :
WT-6089
Certification :
CE
Place of Origin :
Guangzhou
MOQ :
1 Set
Price :
10000USD-170000USD
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
70 Set/Month
Delivery Time :
15days
Packaging Details :
Woodcase(Inner with PE packaging film)
Applicable products :
Wine/Beer/Beverage
Delivery :
20days
Label width object :
190mm
Condition :
Customized
Accuracy :
±0.5mm
Controler :
PLC Touch Screen
Description

Automatic Two Sides Bottle Labeling Machine Adhesive Label Sticker Shampoo Wine


Products Description

1 , Powerful performance: labeling different sizes of containers sticking two sides of labels

2 , High precision and stability: PLC control system, stepping motor drives, U-type sensor detects

3 , Colorful touch screen, English display, convenient operating interface.

4 , Able to store 20 kinds of labeling data, easy to shift different products, no need to re-set.

5 , Stainless steel+ aluminum alloy construction, easy maintenance, durable life.

6 , Option parts: bar code or date code printer or reader time.

7 , The words in the ribbon are clear and clean,the quick printer adopts the motor drive,gas drive..

8 , The whole label applicator is designed to meet GMP standard.

9 , This presure-sensitive label machine is suitable for medicine,chemical,food,commodity etc.Labeling for

10 , bottle and box of flat,square,circle,elliptic,tapered,single orientation etc.

11 , This automatic labeller adopts imported stepping motor control,Japan fiber, Taiwan technolog,Ensure labeling machines quality.

12 , Use the flexible adjustment of the pressure the top agencies and guides,ingenious design for
combination of mechanical and structural adjustment and the winding labels. labeling location can be fixed after adjustment, so that it is simple and time-saving for adjustment of the conversion between different products and labels Winding.

Features


1 , This machine can automatically attach adhesive labels or stickers film on the side surface of the product/ large curvature, circumference, and square surface, etc.

2 , Double sides rigid with simultaneous oriented chain, can make sure the bottles on the middle automatically.For flat bottles, square bottles, arc bottles.

3 , Improve product competitiveness. Attached location is accuracy and stable; to avoid manual labeling, inefficient film, attached skew, foaming and folds, and irregular attached location problems, reduce cost, make product more nice.

4 , Use PLC control system, touch screen, has standard sensor electronic control system, human control interface show prompted comments and complete function, operation function, easy to use and maintain.

5 , Labeling smooth, not wrinkled, no bubbles, labeling accuracy, high efficiency, good stability.

6 , Use PLC control system, touch screen, has standard sensor electronic control system, human control interface show prompted comments and complete function, operation function, easy to use and maintain.

7 , Well-knowen motor drive is matched with the complete machine that ensures a stable and reliable label-feeding speed.

8 , The sensor detect the product,transmit the signal to labeling control system;

9 , Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

10 , No pollution,Running in a high automatization and intellectualization.

11 , Beautiful appearance, beautifully designed, small size, saving plant space, the use of high efficiency machines.

Application


1 , The machine applys to sigle side, double and facade labeling of all kinds of quadrate & flat bottles in pharmacy, food beverage, daily chemical industry etc.

2 , Start-up system: depend on 3-5 pole motor driving, electronic control speed, full automatic transmission device, electrcity source place conbine with high precise density steel star gear, including automatic suited machinery safty device.

3 , The machine adopts PLC process control, photo-electricity bottle checking and label delivery.

4 , The machine are composes of high production effiency, labeling precise and reliable, operation convenience, and wide adaptive scope etc.

Technical Parameters

Production speed 45m/min
Labeling accuracy ±1mm
Label max width 190mm
Bottle diameter 30-100mm
Label inner diameter 76.2mm
Label outer diameter Max330mm
Outline size L2000×W700×1400mm
Air source 4-6KG 30L/MIn
Using power

220V 50HZ 1200W



Advantages

1 , This machine suit for double sided labeling of the square bottle,flat bottle and round bottles.

2 , Installed round bottle institution on it ,realize round bottle labeling ,plus one sensor ,can realize orientation labeling of the round bottles.The speed is around 2500B/H,max label high 168mm (accept custom).

3 , Using 82.6mm chain board width ,Suit for diameter / width 30-110mm bottles,flat bottle,round bottle,square bottle and some irregular bottles.

4 , Labeling head: new design,more stable,width 200mm,suit max label high 190mm,eight orienation adjustment.

5 , Machine can work with ribbon date printer and injek printer.

6 , When you have a lot of kinds of bottles,when labeling,only need to adjust machine.

7 , Only need to adjust oval bottle synchronous chain correcting device,for oval bottle.



Product Details

Automatic Two Side Bottle Labeling Machine Adhesive Label Sticker Shampoo Wine
Automatic Two Side Bottle Labeling Machine Adhesive Label Sticker Shampoo Wine
