Liqueur Round Glass Bottle Adhesive Labeling Machine Alcohol Industry
Liqueur Round Glass Bottle Adhesive Labeling Machine Alcohol Industry
Specifications
Brand Name :
Boson
Model Number :
WT-630GD
Certification :
CE
Place of Origin :
Guangzhou
MOQ :
1 Set
Price :
10000USD-38000USD
Payment Terms :
T/T, L/, Western Union, L/C
Supply Ability :
40 Set/Month
Delivery Time :
20days
Packaging Details :
Woodcase(Inner with PE packaging film)
Production speed :
45m/min
Labeling accuracy :
±1mm
Label outer diameter :
330mm
Function :
Labeling stiicker labels
Supply of power :
1200W
Labeling range :
30-100mm bottles
Description

Liqueur Round Glass Bottle Adhesive Labeling Machine Alcohol Industry

Technical Parameters

Production speed

45m/min

Labeling accuracy

±1mm

Label max width

190mm

Bottle diameter

30-100mm

Label inner diameter

76.2mm

Label outer diameter

 Max330mm

Outline size

L2000×W700×1400mm

Air source

4-6KG 30L/MIn

Using power

220V 50HZ 1200W

Product Characteristic

1 , Wide application, adapt to the dimension of 10-100mm round bottle labeling.

2 , High accuracy, and the error of label joining part is no more than 0.5mm

3 , Adopt extrusion device to feeding, just need to put work- pieces, the machine can automatically finish labeling.

4 , Use chuck type to adjust, different work-piece can cut over easily.

5 , Use the synchronous belt, the stability of the mechanism is greatly improved.

6 , Desktop design, make the structure simple, figure small and function strong.

7 , Anode corundume alloy shelf and the deluxe computer white electricity box make

the figure beautiful and generous.

8 , Advanced magic eyes, make the sensitivity high for the object and label

Advantages

1 , Most component are made by aluminum,cutting the weight and cutting the transportation fees.

2 , The production max speed is about 45m/min.Labeling accuracy is ±1mm.

3 , The machine’s Using power,dimension,Weight are customized.

Application

1 , The machine is apply to the Daily Chemical and Food Industry.

2 , Labeling max width is 190mm(can be raised according to the require)

3 , The air pressure pump of air source is 4-6KG,about 30L/MIn.

4 , Bottle diameter:30-100mm, Label inner diameter is 76.2mm,max outer diameter is 330mm.

Bottle's Sample

Liqueur Round Glass Bottle Adhesive Labeling Machine Alcohol Industry
