Beverage Industry Round Bottle Sticker Labeling Machine Electric Driven Type
Beverage Industry Round Bottle Sticker Labeling Machine Electric Driven Type
Specifications
Brand Name :
Boson
Model Number :
WT-630GB
Certification :
CE
Place of Origin :
Guangzhou
MOQ :
1 Set
Price :
10000USD-38000USD
Payment Terms :
T/T, L/, Western Union, L/C
Supply Ability :
40 Set/Month
Delivery Time :
20days
Packaging Details :
Woodcase(Inner with PE packaging film)
Production speed :
45m/min
Label max width :
190mm
Label inner diameter :
76.2mm
Usage :
Adhesive Labels Bottles
Main technology :
Imported motor
Driven Type :
Electric
Description

Beverage Industry Round Bottle Sticker Labeling Machine Electric Driven Type

Product Characteristic

1 , Imported electromagnetic clutch and high precision.

2 , Advanced 3.0 anodizing aluminum alloy, longer life.

3 , The name factory motor can meet the heavy load, long time operation.

4 , All spare parts and standard adopt stainless steel material.

5 , PLC control panel, liquid crystal display more fashionable.

6 , Import inspection standard optical coupling, to guarantee the high precision accuracy.

7 , Suitable for the quantity is little and variety of the round bottle labeling of containers, code such as: glass bottle, plastic bottles, tins etc.

Application

1 , The machine is apply to the Daily Chemical,Food,Beverage Industry.

2 , Labeling max width is 190mm(can be raised according to the require)

3 , Bottle diameter:30-100mm.

4 , Label inner diameter is 76.2mm,max outer diameter is 330mm.

5 , The air pressure pump of air source is 4-6KG,about 30L/MIn.

Advantages

1 , Most component are made by aluminum,cutting the weight and cutting the transportation fees.

2 , The production max speed is about 45m/min.Labeling accuracy is ±1mm.

3 , The machine’s Using power,dimension,Weight are customized.

Special note

1 , bottle surface must be cleaning and without water drop before labeling,

2 , Use stainless steel board ,if it need special connect the production line requirement,the price need discussion

3 , During the machine in production,the buyer need bottles and labels roll to manufacture for debugging

4 , The bottle cant be deformation,effect the labeling quality,the gaps between labels must be same,cant have a big difference

Technical Parameters

Production Speed 45m/min
Labeling accuracy ±1mm
Label max width 190mm
Bottle diameter 30-100mm
Label inner diameter 76.2mm
Label outer diameter Max330mm
Outline size L2000×W700×H1400mm
Air source 4-6KG 30L/Min
Using Power 220V 50HZ 1200W

Producing details

Beverage Industry Round Bottle Sticker Labeling Machine Electric Driven Type
