0.75mm Electronic Vertical Wire Drawing Machine For Iron Material 37 - 45kw
0.75mm Electronic Vertical Wire Drawing Machine For Iron Material 37 - 45kw
0.75mm Electronic Vertical Wire Drawing Machine For Iron Material 37 - 45kw
0.75mm Electronic Vertical Wire Drawing Machine For Iron Material 37 - 45kw
Specifications
Brand Name :
Vertical wire drawing machine
Certification :
ISO9001
Place of Origin :
JIANGYIN CHINA
MOQ :
1set
Price :
Negotiated
Payment Terms :
T/T 30% deposit，70% rest payment before shipment
Supply Ability :
2sets/month
Delivery Time :
60days after receiving order and deposit
Packaging Details :
plastic bag
items :
1000
Capstan diameter :
Ø1000mm
Function :
Draw the big size metal wire
Inlet tensile strength :
≦1250Mpa
Drawing speed :
≦80M/Min
Total compression rate :
≦35%
Motor :
110kw
Diameter :
15-25mm
Description

New 0.75mm Vertical Wire Drawing Machine with Draw the big size metal wire

Specifications

  • Wire Drawing machine
  • Vertical type
  • Max wire diameter:2.5mm
  • Min wire diameter:0.75mm
  • drawing wire of high, medium

Vertical Wire Drawing Machine

Suitable

Material

Reel

Diameter

(mm)

Intensity

N/mm2

Inletwire

Diameter

(mm)

Line

Speed

(m/min)

Main Motor

Power (kw)

Machine

Dimension

(m)

Machine

Weight

(kg)

Iron 600-800 ≤1000 6.5-12 60 37-45 3*2.6*2.5 3000-4500

Structure:

The equipment consists of main reduction box,die casing,wheel frame,sash brace and

electrical control system.The spinning drawing blocks are driven by JZT series motor,with gear coupling runs changeful gears to reduce speed. The drawing blocks are verticaly fixed in sealed box body.The gear pair are lubricated with oil.

Usage:

The set of the machines is an ideal equipment for drawing wire stock of high,medium and carbon steel,as well as coper,alumium and alloy.The machine are applied for drawing wire in the factories,such as wire-steel factor,metal mesh factory and nail making factory etc.

In order to lower residual heat on the surface of the block, the cooling means is installed in inter-wall of the block,the wortle is soaked in cooling water to reduce its working temperature.

Why let you choose us?

1. Production experience:Absorbed ,Professional for 13years

2. Each link strict control the quality

3. Our goals are not do the lowest price to do the best quality

4. Life provides you with technical guidance

5. The long-term supply all kinds of spare parts, make sure that you use perennial

6. To offer our customers workshop design

7. Choose a professional supplier will bring you more convenient
