Heavy Duty Spoke Type Load Cell , Fatigue Resistant Industrial Load Cells
Heavy Duty Spoke Type Load Cell , Fatigue Resistant Industrial Load Cells
Heavy Duty Spoke Type Load Cell , Fatigue Resistant Industrial Load Cells
Heavy Duty Spoke Type Load Cell , Fatigue Resistant Industrial Load Cells
Specifications
Brand Name :
ruijia
Model Number :
RJ-9200
Place of Origin :
China
MOQ :
1pc
Price :
USD25-80/pc
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
2-4 weeks
Packaging Details :
Standard export packaging
Usage :
Pressure Sensor
Output :
Analog Sensor
Comprehensive error (%F.S) :
±0.05
Safe overload (%F.S) :
150
Application :
truck scales,hopper scale and other weighing devices
Material :
alloy steel or stainless steel
Description

30 ton Heavy duty Spoke Type Load cell fatigue resistant Truck Scales sensors

What is strength of Load cell?

1. Made of alloy steel or stainless steel

2. Suitable for belt weigher, hopper scale and other weighing devices

3. Good steel performance and high accuracy

What is load cell?

Load cell is the heart of electronic weighing apparatus. As the rapid development of sensor technology, electronic weighing apparatus have been widely used in many industrial areas. It is used in tank scales, hopper scales, hanging scales, vehicle scales, and other scales or control systems that require fast and accurate force measuring.

What is specifications of Load cell?

Capacity

T

40

Sensitivity

mV/V

1.5±0.15

Combined Error

%FS

0.02

Creep(15min)

%FS

0.02

Input Resistance

Ω

350±5

Output Resistance

Ω

350±5

Insulation Resistance

M Ω

≥5000(50VDC)

Zero Balance

%FS

±1

Temperature Effects on Span

%FS/10℃

0.02

Temperature Effect on Zero

%FS/10℃

0.02

Rated Temperature Range

℃

-10～+60

Operating Temperature Range

℃

-20～+80

Proposed Excitation Voltage

V

6～12

Allowed Excitation Voltage

V

3～15

Safe Overload

%FS

120

Ultimate Overload

%FS

150

Protection

IP65

Material

Alloy Steel

What is Dimension of Load cell?

Heavy Duty Spoke Type Load Cell , Fatigue Resistant Industrial Load Cells

Range

Size (mm)

T

φA

φB

φC

φF

MD

H

E

0.5-7

105

88.9

6.5

32

M16x1.5

37

34

10-25

125

101.6

8.5

39

M32x1.5

52

48

30-50

145

116.8

10.5

50

M40x1.5

58

54

60-100

205

162

12.5

80

M60x2

85

78

Range (T)

Size(mm)

φ

L1

L

M

SR

0.5-7

31

13

28

M16*1.5

80

10-25

38

24

51

M32*1.5

120

30-50

50

32

62

M40*1.5

200

60-100

80

42

80

M60*2

280

What is application of Load cell?

Heavy Duty Spoke Type Load Cell , Fatigue Resistant Industrial Load Cells

Packaging & Shipping

Packing

Standard export package: each unit has individual box and all boxes are packed in standard packages.

Shipping

Products are shipped from china. We will sent out within 15 working days after the payment. We usually send the parcel by DHL, EMS and TNT etc. The tracking number will be sent to you after delivery. It usually takes 3--5 working days to reach your side which depend on the country delivery to.

Our Services

Service standards: we are committed to provide a high quality and responsive service to all clients

The fastest reply: Please feel free to contact us if you have any questions. You will get a reply from the professional and experienced trade manager within 24 hours. If our trade manager is off line, please leave a message, and tell us the product model you need and your E-mail address.

Quality assurance: good quality is assured by advanced manufacturing technology. And all products are through strict test by our professional QC team before shipping.

Door to door service: We usually send the parcel by DHL, EMS and TNT etc. The tracking number will be sent to you after delivery. It usually takes 3--5 working days to reach from from our side to your side, which is very convenient for your business

OEM available

FAQ

1. What detailed information do I need to provide if I want to place an order?

We need to know the following information: Capacity, Usage and other related parameters you need.

2. Do you have any discount?

Yes, if you buy large QTY, please send us a email, we will give you a big discount.

3. What terms of payment are available?

We accept T/T, L/C, Trade assurance, Secure payment, Western Union, Paypal, Money Gram, etc.

4.When will you arrange the production?

We will arrange the production immediately after receiving your payment.

5. How do you ensure good product quality?

We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.

Product tags

aluminum load cell

,

industrial load cell

,

spoke type load cell
