Specifications
Brand Name :
Ruijia
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
USD 50~71/piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000 Piece/Pieces per Month
Delivery Time :
Within 2Weeks
Packaging Details :
Standard export packaging
Material :
Cast aluminium housing
Product number :
Duct pressure transmitter, dry gas differential pressure transmitter
Measuring range :
-100-100Pa ~ 0-10KPa
Output :
1-5v/0-5V/4~20mA/0~10V/rs485
accuracy :
0.5
material :
aluminum alloy
Installation thread :
diameter 8mm pagoda head
Electrical connectors :
directly qualify
Description

Micro Intelligent Dry Gas Pressure Transmitter , Digital Air Wind Differential Pressure sensor with 4-20ma /0-5v /0-10v

Features:
1. Adopting US imported 5651 chips;
2. The selected patching process has zero point, full scale compensation and temperature compensation;
3. High-precision and high-stability amplifying integrated circuits have the functions of moisture proof, anti-condensation, anti-leakage and lightning protection;
4, the minimum pressure range can reach 1Pa, the maximum can achieve 100KPA! Part of the negative pressure can also be done! Various output signals are commonly used 4~20mA 0~10V 0~5V, etc.

Product Description

The wind pressure and differential pressure transmitters are the standard form of our company's transmitters. It adopts imported high-precision, high-stability chip, which is assembled by aluminum alloy shell and stress isolation technology. It is processed by precision temperature compensation and circuit amplification technology and converted into 4-20m or 1-5V, 0-5V, 0-10V. Standard signal output, interface with industrial computer or distribution system, widely used in the measurement of air duct pressure or differential pressure of petroleum, chemical, metallurgy, power plant, etc., so as to realize the automatic measurement control of the production process. The transmitter is compact and sturdy, light in weight and easy to install. The zero range can be continuously adjusted externally and has a wide migration range. It is suitable for measurement of various gas pressures or differential pressures with high measurement accuracy and good stability!

Specification

item
value
Warranty
1 years
Customized support
OEM
Place of Origin
China
Shaanxi
Brand Name
kexlimice
Model Number
ESMDPSW
Material
Cast aluminium housing
Product number
Duct pressure transmitter, dry gas differential pressure transmitter
Measuring range
-100-0Pa-100kPa
Measured medium
dry gas
Pressure type
differential pressure, gauge pressure
Pressure resistance
three times the range value (usually referred to as the single end maximum pressure)
Output:
Analog output: 4 to 20 mA (two-wire system), 0 to 5 VDC (three-wire system), 0 to 10 VDC (three-wire system)
Comprehensive accuracy:
±0.5%FS , ±0.2%FS
Power supply
24V Dc
Interface
8mm tower interface
Temperature:
-20~85°C
Shell:
Die-cast alloy aluminum, self-weight: 0.5KG

Micro Intelligent Dry Gas Pressure Transmitter , Digital Air Wind Differential Pressure Sensor With 4-20ma /0-5v /0-10v

Company Profile
Micro Intelligent Dry Gas Pressure Transmitter , Digital Air Wind Differential Pressure Sensor With 4-20ma /0-5v /0-10v
Xi'an Ruijia Measuring Instruments Co., Ltd. launch its journey as a quality products manufacturer. We are currently producing precision series of products like pressure transmitter ,differential pressure transmitter,ultrasonic sensors, ultrasonic level meter, displacement sensors, safety light curtain sensor,float switch, flow meters etc. A core of highly profession and experience engineers are engaged with us for research and development process. Our range of equipment boundary expanded recently to GPS tracking equipment . Since its establishment, the company growing up to a design and supply chain services. We, developed into a sensor and GPS tracking solution provider, for distributors and agents both at home and abroad. Today, the company based on the "people-oriented, scientific and technological innovation" concept of the camp, with customers "buy for peace of mind with assured quality", to set foot in the world market. Welcome to Xi'an Ruijia with innovative solution worldwide.

FAQ

1. What detailed information do I need to provide if I want to place an order?

We need to know the following information: Capacity, Usage and other related parameters you need.

2. Do you have any discount?

Yes, if you buy large QTY, please send us a email, we will give you a big discount.

3. What terms of payment are available?

We accept T/T, L/C, Trade assurance, Secure payment, Western Union, Paypal, Money Gram, etc.

4.When will you arrange the production?

We will arrange the production immediately after receiving your payment.

5. How do you ensure good product quality?

We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.


Looking forward to cooperating with you!
