0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
Specifications
Brand Name :
JIATUO
Model Number :
JT-WM001
Certification :
CE, ISO
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
500 set/month
Delivery Time :
7~10working days
Packaging Details :
plastic film or other standard package for sea shipping
Product type :
Full automatic strap winder
Core Components :
PLC, Motor
width of strap :
4-20 mm
Supply :
three -phase four -wire AC power
Keywords :
PP packing strap production line extrusion machine
Warranty :
1 Year
After-sales service provided :
Engineers available to service machinery overseas
HS Code :
3920690000
Description

Electrical Control Plastic PP PET Packing Belt Extruder Machine With Double Disk Winder

PRODUCT DESCRIPTION

PET/PP strap is known as plastic steel band, which is used in place of steel on the world of a new environmentally friendly packaging materials, the development of new materials in recent years the cost of success and a substantial decline, have been widely used in the steel industry, chemical fiber industry, aluminum ingots, paper, brick kiln industry, screw industry, tobacco industry, electronics, textiles and wood, etc.; is replaced by a new high-strength steel strapping, is the worlds most widely used for steel products.

Max winding diameter 500mm
Max winding width 220mm
Max winding line speed 280m/min
Motor power 1.5kw
Winding displacement motor power 750w


0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
TECHNICAL SPECIFICATION

  • For the PET strap packing into a roll. The center automatically arranged winding. Consists of: closing reel, core, transmission unit, winding displacement unit, rack, electrical control parts, etc.
  • Torque arm directly separately checks the location and pneumatic plug to maintain the tension of straps.
  • Automatic computer control winding disk diameter and length of the winding.
  • Winding parameters, cable parameters can be set according to the product specifications by computer.
  • Servo motors are used to control the width and spacing of winding displacement.
  • Straps entrance with protection device.

Features of PET strap, PP strap Winder Machine

(1)Special twin screw extrusion technology and single screw extrusion technology can be choosing as per
customer needs.
(2) Process 100% recycled PET bottle flakes.
(3) Even plasticization and stable extrusion with PLC automatic control for the full line.
(4) As per different requirements, changing a coating materials for make strap have better and special function.
For example, the strap for packing cotton can be from enhancing the breaking strength and joint strength
when welding strap.
(5) Melt filter with two pistons with air venting design and back flushing.
(6) Number of strap:1,2,4,6,Width: 9mm-20mm,Thickness: 0.6mm-1.5mm
(7)Workers: 2 -3 workers per shift, 12 hours/shift.

0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine

TURNKEY PROJECT SERVICE

1. We will provide all the machines for the complete production according to customer's requirements.
2. We will provide complete service for factory layout and other information to help customer to build the factory.
3. We can also provide the raw material to the customer if need.
4. We will provide good service for machine installation and training, until the customers can run the machines and make stable production.
5. Except one year quality guarantee, we will provide after-sell service for all the life.
6. For long-term cooperation, we always provide good quality, good price and good service to customer. We are the professional and trustable supplier for turnkey projects. Let us do win-win business together.

0.6mm-1.5mm Thickness PP Strap Machine Double Disk Strapping Band Winding Machine
