Specifications
Brand Name :
JIATUO CHINA
Model Number :
JTPET-100
Place of Origin :
CHINA
Certification :
IS CEO
MOQ :
1 SET
Price :
Negotiable
Packaging Details :
plastic film
Delivery Time :
50-60days
Name :
PET Strap Making Machine
Strap Width :
9-32mm
Raw material :
PET bottle flake material
Paper tube size :
¢406*150mm
Inverter :
45KW(INVT)
Extrusion quantity :
4
Strap Core Material :
Paper/Plastic/Aluminum
Strap Tension :
150-850kg
Description

Polyester Polyethylene Terephthalate PET Straps Band Production Line Plastic Pet Strap Making Machine,PET plastic steel

Product Description:

This PET Strap Making Machine is a high-performance, automatic machine designed for the production of PET straps. It features a robust and reliable design that allows it to handle large-scale strap production with ease. It is capable of producing straps with a width of 9-32mm and can be used to produce straps in white, black, blue, green, and other colors.

The design of this machine is based on the principle of high-end intelligence, advanced technology, first-class technical parameters, we have more than 30 years of production experience in the PET packaging belt industry, and have their own plastic steel belt factory.

The machine has a PLC control interface for easy operation and monitoring of the belt production process. It also provides some security features that automatically save parameters during the process to protect the same specifications.

This PET Strap Making Machine is an excellent choice for any large-scale production, offering fast and efficient strap production with superb quality. It offers a reliable and durable design that allows for a long and trouble-free service life. This machine is an ideal choice for any production facility that requires high-quality PET straps in large quantities.

Polyester Polyethylene Terephthalate PET Straps Band Production Line Plastic Pet Strap Making Machine,PET plastic steel

Features:

  • Product Name: PET Strap Making Machine
  • Strap Color: White/Black/Blue/Green Etc.
  • Strap Width: 9-32mm
  • Raw material: PET bottle flake material&100% broken material
  • Strap Core Material: Paper/Plastic/Aluminum
  • Features: Double cylinder/Single cylinder, 100% recycled bottle flakes material

Technical Parameters:

Model

Width

Thickness

Pull

Gross weight

Net weight

Paper core diameter

Length

 Other models
PET-0950 9.0mm 0.50mm >150kg 20kg 18.5kg 200/406mm 3400m PET-1610
PET-1050 10.0mm 0.50mm >180kg 20kg 18.5kg 200/406mm 2900m PET-1970
PET-1250 12.0mm 0.50mm >210kg 20kg 18.5kg 200/406mm 2400m PET-1910
PET-1260 12.0mm 0.60mm >220kg 20kg 18.5kg 200/406mm 2000m PET-1912
PET-1360 13.0mm 0.60mm >250kg 20kg 18.5kg 200/406mm 1850m PET-2512
PET-1660 16.0mm 0.60mm >320kg 20kg 18.5kg 200/406mm 1500m PET-3512
PET-1670 16.0mm 0.70mm >370kg 20kg 18.5kg 200/406mm 1300m
PET-1680 16.0mm 0.80mm >450kg 20kg 18.5kg 200/406mm 1200m

Polyester Polyethylene Terephthalate PET Straps Band Production Line Plastic Pet Strap Making Machine,PET plastic steel

Applications:

The JIATUO CHINA JTPET PET Strap Making Machine is a top-tier product with a high-quality design and construction. It is perfect for a variety of applications and scenarios due to its many features. It is certified IS CEO and has a minimum order quantity of 1 SET. The price is negotiable and it is delivered within 50-60 days. The power supply is 220V/380V and the strap core material can be paper, plastic, or aluminum. The strap tension range is 150-850kg and the strap material is PET with a strap width of 9-32mm.

This machine is perfect for businesses looking to make PET straps with 100% recycled bottle flakes material. It has a double cylinder or single cylinder design with a PLC control system. The cutting speed and tension is adjustable for a high efficiency and low noise. It has a good stability and is easy to operate with a low maintenance cost.

FAQ:

Q1: What is the Brand Name of the PET Strap Making Machine?

A1: The Brand Name of the PET Strap Making Machine is JIATUO CHINA.

Q2: What is the Model Number of the PET Strap Making Machine?

A2: The Model Number of the PET Strap Making Machine is JTPET.

Q3: Where is the PET Strap Making Machine made?

A3: The PET Strap Making Machine is made in China.

Q4: What is the Certification for the PET Strap Making Machine?

A4: The Certification for the PET Strap Making Machine is IS CEO.

Q5: What is the Minimum Order Quantity for the PET Strap Making Machine?

A5: The Minimum Order Quantity for the PET Strap Making Machine is 1 SET.
