Drum Upright Turntable Transmission Line Stringing Tools For Tension Stringing Conductors
Drum Upright Turntable Transmission Line Stringing Tools For Tension Stringing Conductors
Specifications
Brand Name :
Boyu
Model Number :
TYWFJ
Place of Origin :
China
MOQ :
10 sets
Price :
Negotiable
Payment Terms :
T/T, L/C
Delivery Time :
25-30days
Packaging Details :
Container
Certification :
ISO9001
OEM :
available
After sales service :
available
Rated load :
30kn
Drum diameter :
1200mm
Weight :
170kg
Description

Drum Upright Turntable Transmission Line Stringing Tools For Tension Stringing Conductors

Quick details:


1. Transmission Line Stringing Tools
2. Drum Upright Turntable
3. Weight: 50,60,170kg
4. Rated Load: 20~50kN
5. Drum Max Diameter: 1200mm
6. Boyu Brand

Description:

The drum upright turntable are made of welded steel with protective coating.It’s suitable for tension stringing of conductors and ground cables, while putting the drum in the six-equal rolling disk.There are two pulleys for each set with a rolling bearing in the middle.


Specification:

Model

Rated load (KN)

Drum diameter (mm)

Weight (kg)

TYWFJ20

20

800

50

TYWFJ30

30

1000

60

TYWFJ50

50

1200

170

Maufacturer Introduction

Yixing Boyu Electric Power Machinery Company is located in west side of the beautiful and fertile Taihu Lake. We are at the east of China, near Shanghai seaport, Nanjin airport, Hangzhou airport, about 2~3 hours by car.
Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:
  • Line Stringing Equipment and accessories and tools.
  • Nonmetallic galvanized the production equipment (Achieved high-tech products)
  • Numerical control machine
  • Low voltage no power-arc furnace compensation system
