Pulling Type 2 x 50KN Hydraulic Cable Tensioner With Twin-bundle conductor

Quick details:

1.Tension Stringing Equipment

2.Pulling Type 2x50KN Hydraulic Cable Tensioner

3.Main parts German Rexroth
4.Max tension 2X50kN

5.Boyu Brand
6.Engine Cummins
7.Twin-bundle conductor

8.Operating handle: German Rexroth

Use

The machine allows for the tension stringing of twin-bundle conductor of 630mm2 and below in mountainous and hilly areas, of twin-bundle conductor of 720mm2 and below in flat lands, and of conductor 720mm2 in various terrains; besides, it can be used for tension stringing of OPGW or ADSS optical cable and 500kV haulage rope in various terrains

Main comfigurations

Engine:Cummins

Main motor:German Rexroth

Speed reducer :German Rexroth

Hydraulic meter: German

Operating handle: German Rexroth

Performance parameter

Max continuous tension: 2*50KN

Corresponding speed:2.5km/h

Max continous laying speed:5km/h

Corresponding tension:2*50KN

Structure parameter

Tension wheel diameter:1300/1500mm

Max diameter of applicable :40mm

Groove number:5

Total weight:6000kg

overall dimension (length*width*height):4700*2300*2700mm

Manufacturer Introduction

Jiangsu Province Yixing Boyu Electric Power Machinery Company is located in west side of the beautiful and fertile Taihu Lake. Near Shanghai seaport and Nanjing airport.
Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters.
Established in 1994, Yixing Boyu Electric Power Machinery Co., Ltd. is a manufacturer specialized in the research, development and production of Electric Power Machinery.
We are located in beautiful and rich city: Yixing city. We are a High-tech enterprise in Jiangsu Province, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
　　1. Main configurations of our machine are from Germany and USA
　　Engine: American Cummins
　　Main pump: German Rexroth
　　Main motor& speed reducer: German Rexroth
　　Tail bracket hoisting motor: American Eton
　　Hydraulic meter: German
　　2. Our company was founded in 1994, having 27 years rich experience in this field. Our product sells in distant markets: Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Germany etc. Our product is also very popular in china.
　　3. We have one year quality guarantee, if internal components go wrong within one year, we will change another for free.
　　4. We can supply the specific components to the buyers with cost price after warranty period.

Our service

Quality, loyalty and service is our faith!

1.Deemed continuous improvement as our permanent pursuits.

2.We have introduced many advanced equipments and mature techniques, to meet various of customers’ requirements.

3.We can adjustment the price according to your market demand’s changes, and also can launch a series of promotional activities in a bad economic environment.

4.We will do our best to deal with the problems our customers encountered, in order to ensure our customers' satisfaction and also improve our better reputation.

5. 24-hour hot line: 86-0510-80329270. Once receive the customer’s enquiry , we will response within 24 hours.

6.Do the best Pulling Type 2x50KN Hydraulic Cable Tensioner Tension Stringing Equipment in China.
