Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment
Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment
Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment
Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment
Specifications
Brand Name :
BOYU
Model Number :
TY180-37
Certification :
ISO9001
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100sets/month.
Delivery Time :
15~25 days
Packaging Details :
Container
Type :
Puller Machine For Transmission Line
Bull-wheel diameter :
750mm
Groove number :
10
Max rope diameter :
28mm
Max diameter of rope reel :
1400mm
Overall dimension (length*width*height) :
5000x2300x2500mm
Max pull :
190kN
Diesel :
325hp Euro III, 4-stroke cycle, turbo-charged
Description

TY180 Conductor Stringing Equipment Puller Machine For Transmission Line Max Continuous Pull 180kN

Bull-wheel diameter

750mm

Groove number

10

Max rope diameter

28mm

Max diameter of rope reel

1400mm

Total weight

6700kg

Overall dimension (length*width*height)

5000x2300x2500mm

Max pull

190kN

Max continuous pull

180kN

Speed at max pull

2.5km/h

Max speed

6km/h

Pull at max speed

75kN

Engine

Cummins

Hydraulic pump

German Rexroth

Main motor

German Rexroth

Speed reducer

German Rexroth

Tail bracket hoisting motor

American Eton

Hydraulic meter

German

Operating handle

German Rexroth

Diesel

325hp Euro III, 4-stroke cycle, turbo-charged

Cooling system

liquid

Electrical system

24V

Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment

Other Models

Model TY40 TY60 TY120 TY150 TY220 TY280 TY380
Max intermittent pull KN 40 60 120 150 220 280 380
Max continuous pull KN 30 50 100 120 180 250 350
Speed at max pull km/h 2.5 2.5 2.5 2.5 2.5 2.5 2.5
Max speed km/h 5 5 5 5 5 5 5
Pull at max speed KN 20 25 50 60 90 120 170
Diesel kw(hp) 77(103) 77(103) 129(173) 129(173) 239(320) 298(400) 440(590)
Cooling system Water Water Water Water Water Water Water
Electrical system V 24 24 24 24 24 24 24
Bull-wheel diamete mm 400 450 600 600 760 960 960
Groove number 7 7 10 10 10 11 11
Max rope diameter mm 16 18 24 24 30 38 38
Max diameter of rope reel mm 1200 1400 1400 1600 1600 1600 1900
Total weight kg 3000 3500 4800 5500 6800 12800 13600

Company Profile
  • Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents.
  • Our company has a total area of 42800 square meters, having formed four series products:
►Electric power construction tools
►Nonmetallic galvanized the production equipment (Achieved high-tech products)
►Numerical control machine
►Low voltage no power-arc furnace compensation system

Our Certificate

Our company has passed CE certification.

Our company has passed ISO9001 certification.
