Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
Specifications
Brand Name :
BOYU
Model Number :
TY1X60
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100sets/month.
Delivery Time :
25-35 days
Packaging Details :
Container
Bull-wheel diameter :
1500mm
Groove number :
6
Total weight :
4800kg
Max intermittent pull :
70kN
Max continuous pull :
60kN
Speed at max pull :
2.5km/h
Diesel :
77kw(103hp)
Engine :
Cummins
Speed reducer :
German Rexroth
Operating handle :
German Rexroth
Description

Overhead Line Stringing Equipment Diesel 77kw(103hp) Hydraulic Tensioner Max intermittent pull 70kN

Quick Detail:

  • Bull-wheel diameter: 1500mm
  • Max conductor diameter: 40mm
  • Groove width: 65mm
  • Groove number: 6
  • Total weight: 4800kg
  • Overall dimension (length*width*height): 4300×2050×2600mm
  • Max intermittent pull: 70kN
  • Max continuous pull: 60kN
  • Speed at max pull: 2.5km/h
  • Max speed: 5km/h
  • Pull at max speed: 35kN
  • Max reverse pulling force: 50kN
  • Max reverse pulling speed: 5km/h
  • Engine: Cummins

  • Hydraulic pump: German Rexroth/Dnish Danfoss

  • Main motor: German Rexroth/French Leduc

  • Speed reducer: German Rexroth

  • Hydraulic meter: German

  • Operating handle: German Rexroth

  • Diesel: 77kw(103hp)

  • Cooling system: water

  • Electrical system: 24V

Hydraulic Transmission The machine can realize step less speed.
The machine is provided with tension presetting system.
Configuration Hydraulic dynamometers
Hydraulic oil cooling system
Electric meter counters

Grounding connection point
Additional Devices Lighting system for the trailer
Hydraulic rope clamp for reel change(extra charge)
Swivel guide rope roller
Trailer for towing at max speed of 30 km/h
Extra shaft
Digital speed and meter counter

The machine uses hydraulically controlled tension and is equipped with high quality parts and components such as hydraulic crushing, high performance finned radiators, hydraulic power units, precision filtration units to support safe, high quality and efficient performance. The hydraulic power unit provides traction of the conductors in the positive and negative directions.

A single beam trailer chassis is also employed in which the lifting points are pre-set for anchoring and temporary anchoring for portable compact integrity that is easy to load, transport and transfer.

Hydraulic Tensioner Underground Cable Pulling Equipment Max Intermittent Pull 70kN
