Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Specifications
Place of Origin :
Guangdong, China
Model Number :
S-12-12
Certification :
CE
Packaging Details :
Standard Neutral Carton box Package
(One-stop Lighting Power Supply Solution Matching Service, welcome to consult)
Price :
Negotiation
MOQ :
Negotiation
Payment Terms :
T/T
Supply Ability :
10000pcs/month
Delivery Time :
3-10days
Output Power :
12W
Input Voltage :
AC100V-240V
Output Voltage :
12V
Output Frequency :
50-60Hz
Output Current :
1A
Product Name :
Chassis Switching Power Supply
Application :
LED Lighting
Type :
AC DC Power Module Converter
Efficiency :
93%
Weight :
70g
Size :
L70*W40*H30mm
Protection :
OCP OVP SCP OPP
Description

100V 240V AC to DC 12Volt 12W 1A Switching Power Supply Aluminum Case LED Strip Light Driver

Ac to Dc 12V Power Supply Constant Voltage Regulated Power Supply 12V 1A 12W LED Power Supply Driver for Electronic Appliances

1.High efficiency, long life and high reliabili
2.Low dc ripple, high efficiency
3.low operation temperature & long performance life
4.input voltage suitable for all over the world
5.Excellent insulation property, high dielectric strength
6.100% full-load burning test
7.2 years warranty
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Thickened metal shell
The shell is made of high-quality metal material with good pressure resistance. Heat dissipation is fast. Durable and Corrosion Resistant
Featured Components
Selected high-quality components, sufficient power. Stable output, energy saving and safer
Suitable for a variety of electronic devices
Products are widely used in industrial automation control, LED lighting, industrial control equipment, communication power equipment, instrumentation, medical equipment, liquid crystal displays, digital products and instruments and other fields
Model
S-12-12
AC input voltage range(V)
AC100-240V
AC Input current(max)
0.05A /AC220V;0.1A/AC110V
Frequency (Hz)
50/60Hz
Efficiency
93% Typ(230VACFull Load)
Inrush current(A)
Cold-start 20A/230V
Leakage current(mA)
<3mA/240VAC
Output Voltage(V)
DC 12V
Voltage Range
12V±5%
Output Current(A)
1A
Current Range (A)
0-1A
Rated Power(W)
12W
Start time,hold-up time(ms)
Ton≤1000ms,Td≥20ms @230Vac Full Load
Rise time(ms)
Typ:20ms @230Vac Full Load
Ripple/Noise(mVp-p)
120mVp-p
working Temperature (°C)
-40°C - +65°C(refer derating curve)
Storage Temperature(°C)
-20°C - +60°C
Humidity
20% - 90% RH non condensing
Over voltage Protection
>115%-135% Rated output voltage
Over load Protection
>105%-150% Auto recovery
Short circuit Protection
Latched
Size L*W*H(mm)
70*40*30mm
Weight
70g
Easy to install and easy to use
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Product Description
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Aluminum Case Switch Power Supply 100V 240V AC To DC 12 Volt 12W 1A
Specification
item
value
Place of Origin
China
Guangdong
Brand Name
Megbox
Model Number
S-12-12
Output Power
12W
Output Type
Single
Input Voltage
AC100V-240V
Output Voltage
12V
Output Frequency
50-60Hz
Output Current
1
Product Name
Chassis Switching Power Supply
Application
LED Lighting
Warranty
2 Years
Certification
CE
Type
AC DC Power Module Converter
Efficiency
93%
Weight
70g
Size
L70*W40*H30mm
Protection
OCP OVP SCP OPP
Protections
Short Circuit Overtemp Overload Overvolt
